API Oil Well Grade Sucker Rod
US$ 10 - 450
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
ERUI
Place of Origin:
China
Model Number:
all size
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO CHINA
Delivery Detail:
7 days
Related Products
-
API 8A CD Type Side Door Elevator/ Wellhead Handing Tools in Oilfield for Oil Well Drill PipeUS$ 1 - 150MOQ: 1 Piece -
Tubing Power Tong Casing Tong Drill Pipe TongUS$ 500 - 10000MOQ: 1 Piece
-
Sucker Rod Elevator, Sucker Rod Hook, Sucker Rod Wrench for Oilfield Wellhead ToolsUS$ 50 - 300MOQ: 5 Pieces
-
API Oil Pumping UnitUS$ 500 - 6000MOQ: 1 Set
-
API 7K Mud Pump Ceramic Cylinder Liners/ Mud Pump Ceramic Cylinder LinersUS$ 95 - 200MOQ: 1 Piece
Brand Name
ERUI
Place of Origin
China
Model Number
all size
After-sales Service Provided
Overseas service center available
Production Capacity
10000
Condition
New
Technical Parameters of Sucker Rod
| SIZE (in) |
ROD D.(in) | THREAD D. (in) |
LENGTH (ft) |
OUTSIDE DIAMETER OF PIN SHOULDER(mm) |
LENGTH OF PIN(mm) |
LENGTH OF WRENCH SQUARE(mm) |
WIDTH OF WRENCH SQUARE(mm) |
| 5/8" | 5/8" | 15/16 | 2 4 6 8 10 25 30 |
31.75 | 31.75 | ≥31.75 | 22.23 |
| 3/4" | 3/4" | 1-1/16 | 38.10 | 36.51 | 25.40 | ||
| 7/8" | 7/8" | 1-3/16 | 41.28 | 41.28 | |||
| 1" | 1" | 1-3/8 | 50.80 | 47.63 | ≥38.10 | 33.34 | |
| 1-1/8" | 1-1/8" | 1-9/16 | 57.15 | 53.98 | ≥41.28 | 38.10 |
Grade and Mechanical Properties
| No. | Grade | Tensile Strength Rel(Mpa) |
Yield Strength Rm(Mpa) |
Percentage Elongation A(%) | Contraction Percentage Of Area Z(%) |
| 1 | C | 620-795 | ≥415 | ≥13 | ≥50 |
| 2 | K | 620-795 | ≥415 | ≥13 | ≥60 |
| 3 | D | 795-965 | ≥590 | ≥10 | ≥50 |
| 4 | KD | 795-965 | ≥590 | ≥10 | ≥50 |
| 5 | HL | 965-1195 | ≥795 | ≥10 | ≥45 |
| 6 | HY | 965-1195 | —— | —— |
Packaging Type
| Dimention | Length(ft) | Pieces/bundle |
Net Weight (KG) |
Gross Weight (KG) |
Remarks(L×W×H) mm |
Adapted Container | Pieces of every Container |
| 5/8" | 25 | 150 | 1930 | 1938 | 7930×550×330 8300×550×330 9440×550×330 |
40'GP/40'OT | 1920 |
| 26 | 150 | 1945 | 1953 | 1920 | |||
| 30 | 150 | 2210 | 2218 | 1690 | |||
| 3/4" | 25 | 100 | 1850 | 1858 | 1345 | ||
| 26 | 100 | 1865 | 1873 | 1334 | |||
| 30 | 100 | 2120 | 2128 | 1174 | |||
| 7/8" | 25 | 80 | 1920 | 1925 | 1039 | ||
| 26 | 80 | 2012 | 2017 | 991 | |||
| 30 | 80 | 2290 | 2290 | 897 | |||
| 1" | 25 | 60 | 1915 | 1923 | 780 | ||
| 26 | 60 | 2006 | 2014 | 744 | |||
| 30 | 60 | 2278 | 2283 | 657 | |||
| 1-1/8" | 25 | 50 | 2044 | 2052 | 609 | ||
| 26 | 50 | 2135 | 2143 | 583 | |||
| 30 | 50 | 2392 | 2398 | 521 |
