The Best Replacement of Traditional Woven Belt
Shengyuan high-speed needle punched corrugated cardboard conveyor belt/Overpass traction belt has advantages as below:
A. High speed, high wear resistance(more than 350m/min)
B. High belt surface flatness, good elasticity, is more beneficial to improve the quality of cardboard.
C. Water absorption and dehumidification performance are better than the similar product in the current domestic and foreign markets.
D. Normal service life is more than 40 million extension meters.
E. There is no significant geometry change of the belt during the whole production process.
THE TESTINGLAB OF CHINA PACKING RESEARCH&TEST CENTER
Patent certificate
No. 2006-1T-005
No. |
Test items |
Unit |
Standard requirements |
Test results |
Conclusion |
1 |
Performance |
/ |
Flat surface Uniform color Warp and weft lines are well textured No hard sundries,defects such as voids,cracks,stains,etc. Straight edge No obvious warping and serrated edges |
Flat surface Uniform color Warp and weft lines are well textured No hard sundries,defects such as voids,cracks,stains,etc. Straight edge No obvious warping and serrated edges |
Qualified |
2 |
Size deviation(width) |
mm |
±10 |
-3 |
Qualified |
3 |
Size deviation(thickness) |
mm |
±0.5 |
0.2~0.5 |
Qualified |
4 |
Mass deviation per unit area |
% |
±3.0 |
2.3 |
Qualified |
5 |
Tensile strength(warp-wise) |
KN/40mm |
≥8.5 |
11.1 |
Qualified |
6 |
Tensile strength(width-wise) |
KN/40mm |
≥4.0 |
6.1 |
Qualified |
7 |
Thermostability(warp-wise stretch) |
% |
-1.5~0.5 |
0.5 |
Qualified |
8 |
Thermostability(width-wise stretch) |
% |
≤2.0 |
1.7 |
Qualified |
9 |
Warp-wise dynamic friction coefficient |
/ |
≥0.32 |
0.38 |
Qualified |
10 |
permeability |
cm³/ (cm³*min*kpa) |
≥0.9*10³ |
0.95*10³ |
Qualified |
NOTE: Sample thickness: 10mm | |||||
The data in the table shows that all test indexes of Shengyuan card needle puncture zone are higher than the national standard.
The sample is taken with a length of 20 mm and a width of 60 mm at a high temperature of 200 ℃ with a tension of 0.72KN for 10 minutes to test the results.
It is proved that the belt keeps the geometric dimension unchanged during normal operation.
Our certificates
For more information please contact:
Email: sales@lnshengyuan.cn, hailey@lnshengyuan.cn
Mob/WhatsApp: +8615140230656
