[Functions and Features]
Pumpkin seeds sheller/hulling machine Model TFBGZ400 is a patented product of our company and is the independent intellectual property of Qiaopai company. It contains 3 national patents. This equipment can dehull pumpkin seeds, water melon seeds and squash seeds, separate shells from kernels and re-separate your products.
It features as following:
-it adopts wet method for dehulling process.
-make it more efficient on dehulling rate and lower broken rate through improvement on existing dehullers.
-it adopts recycled dehulling process, which is to say the unhulled seeds will go back for recycled dehulling automatically.
-It adopts negative-pressure method to suck the shells out instead of blowout to reduce the dust quantity.
-Increase the distance and area of the separation screening, make seed-kernel separation works more thoroughly, thus reduce the persentage of broken due to more kernels going back to dehullers for redehulling.
-The screening section is changeable as per the individual size of the pumpkin seeds
-Compact design, low loss of materials and easy maintenance.
[Component]
1.Cleaning & Sizing Unit
Input hopper, elevator,multifunctional cleaner,bucket elevator,grader(3 sets),electric control cabinet.
It can clean various impurities mixed in pumpkin seeds or watermelon seeds, and then grade the seeds into 6 levels by sizes.
2.Dehulling & Separating Unit
Input hopper, bucket elevator, dehullers, electric control cabinet.
It can shell each grade of pumpkin/watermelon seeds individually,then remove shells from kernels,separate and re-separate un-hulled seeds from kernels.Un-hulled seeds will be returned back to dehuller for re-hulling again automatically.
[ Process]
[ Technical Parameter]
1、Cleaning & Sizing Unit:
Power: 5.71 kW
Input Capacity: 600-800kg/hour
Occupied Area: 14.7m x 2.8m x 2.8m(L*W*H)
2、Dehulling & Separating Unit：
Power: 10.05kW
Input Capacity: 350-400 kg/hour
% of whole kernels: 95% min. (broken kernel is less than 1/2 of whole kernel)
% of seed in the kernels: 2% max.
% of kernels in the shells: 0.3% max.
Occupied Area: 6.25m×1.7m×3.7m(L*W*H)
(Total Weight: 5.5 ton, Operators: 2-3 workers)
