Home > Products > shelling machine > Dry method mungbean peeling machine
Dry method mungbean peeling machine
- 10 Set / Sets per Month
- Dalian
- T/T L/C
You May Like
-
SUNFLOWER SEEDS DEHULLING&SEPARATING EQUIPMENT TFKH1500
-
BUCKWHEAT DEHULLING&SEPARATING EQUIPMENT TFQM400
-
SUNFLOWER SEEDS DEHULLING&SEPARATING EQUIPMENT TFKH1500 HORIZONTAL
-
SUNFLOWER SEEDS DEHULLING&SEPARATING EQUIPMENT (TFKH1500 VERTICAL)
-
SUNFLOWER SEEDS DEHULLING&SEPARATING EQUIPMENT (TFKH1200)
-
OATS DEHULLING&SEPARATING EQUIPMENT
Product Details
| Brand Name | qiaopai | Place of Origin | China | |
| Model Number | TFD600 | Type | dry | |
| Use | mungbean peeling | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | one year | |
| Weight | 6t | Dimension(L*W*H) | 14.5m*2.7m | |
| Production Capacity | 600kg/h | Voltage | 380V | |
| Condition | New | Power(W) | 35.95kw |
Product Description
1.Function and Features
The decorticating and separating equipment (TFD600) for mung beans is our company’s patented product with the independent intellectual property, which contains two national patents, and is a special equipment for peeling mung beans. it can be used to decorticate beans, separate the bran from the decorticated mung beans. The equipment features the following characteristic: higher automatic degree, timing for processing, alarming by sound and light, parking and self-locking, higher percentage of decorticated beans, and better effect for decorticating.
2.Components
The equipment consists of the input hopper, elevator, top-mounted trolley, grinder (4sets), vibrating screen (2sets), sieve for sorting out bran and separating sieve.
3.Process:
Feeding → elevating → conveying → grinding → vibro-screening → sorting out bran → separating → peeled beans
4.Technical Parameter:
Power | 35.95kw (380v 3phase 50Hz) |
Processing capacity | 640kg/h min. |
% of decorticated beans recovery | 75% min. |
% of the whole decorticated beans | 42% min. |
Space occupied | 14.5m*2.7m |
Height | 3.3m |
