Application:
This machine is suitable for foil roll, preservative film, self-seal bag which is packed in the carton.
Main performances and Features:
1. With automatic conveying, opening, feeding, printing(optional), glue spraying, sealing systems. With compact reasonable structure, easy for operation.
2. With servo motors, PLC, touch screen. The display clearly shows the operation data, and design with higher automation.
3. With fully automatic conveying structure, easy connection with full packing lines, saving the labor costs.
4. With automatic photocell tracking system for empty box, and save the materials cost.
5. Easy adjustment for different size of product, suitable for wide range of packaging. No need change the tooling.
6. With automatic stopping and overload protection system for missing box or feeding materials.
Machine Specifications:
Item |
Technical Data |
|
Packing speed |
60-100 carton/min |
|
|
Carton |
Quality requirement |
300-450g/㎡ |
|
Dimension range (L x W x H) |
(110-500)mm X (20-80)mm X (15-60)mm |
|
|
Compressed air |
Working Pressure |
0.5-0.8mpa |
Consumption |
140-180 L/Min |
|
Power Supply |
380V 50Hz |
|
Main Motor Power |
2.2Kw |
|
Total Power |
8.5Kw |
|
Overall Dimension(L x W x H) |
Main Machine: 4300x2300x2000mm |
|
Feeding Structure:1900x300x800mm | ||
G.W. |
2000kg |
|
Suitable for different kind of box sealing type.
Remark: the glue machine can be used from Nordson, Robatech or other brand as per your requirements.
Optional Function: number printing
