1760mm 20-30T/D Multi-dryer and Multi-cylinder Corrugated Paper Carton Machine
- 3 Set / Sets per Month
- Qingdao/Tianjin/Shanghai
- T/T Credit Card
- 2800mm Multi-cylinder and Multi-wire Corrugated Paper Making Machine, Paper Product Making Machinery
- 3800mm corrugated paper equipment chinese manufacturing
- 70t/d kraft corrugated paper mill machinery
- Corrugated medium paper machine,corrugated paper machine
- Corrugated medium paper machine,corrugated paper machine for sale
- Corrugated medium paper machine
Product Details
Condition: | New | Product Type: | Other, corrugated paper making machine | Processing Type: | Paper Slitting and Rewinding Machine |
Place of Origin: | Henan, China | Brand Name: | Jinhua | Model Number: | 1760 |
Voltage: | 380V | Certification: | Other, ISO 9001:2008 | Warranty: | 1 yeat |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
straw rope, wooden package
Product Description
1760mm 20-30T/D Multi-dryer and Multi-cylinder Corrrugated Paper Making Machine
Features:
1. customer-oriented design principle
2. high rate of output with high quality
3. mature skills and technology support
4. considerate pre-sales and after-sales service
5. appropriate discount can be negotiated
Main Equipment Parts:
Cylinder Part | stainless-steel cylinder | 1500mm×2150mm | 4 |
couch roll | 500mm×2150mm | 4 | |
reverse roll | 500mm×2150mm | 1 | |
With 4 pressure mould former | |||
Press Part | stone roll | 650mm×2150mm | 2 |
rubber roll | 600mm×2150mm | 2 | |
Pneumatic compression device | |||
Prepress Part | natural marble roller | 500mm×2150mm |
|
450mm×2150mm |
| ||
Pneumatic compression device | |||
Dryer Part | alloy drying cylinder | 2500mm×2150mm | 1 |
alloy drying cylinder | 1500mm×2150mm | 6 | |
anti-roll | 750mm×2150mm | 2 | |
Pneumatic compression device | |||
Winding Part | 1760mm cylinder winding machine and rewinding machine | 1 | |
Driving & Control part | AC frequency conversion & driving by step |
Equipment List
NO. | Name | Quantity(set) |
1 | 1760mm multi-dryer and multi-cylinder corrugated paper making machine | 1 |
2 | exhausting hood | 2 |
3 | Axial-flow fan | 2 |
4 | 15 type roots vacuum pump | 1 |
5 | suction box | 4 |
6 | pressure mould former | 4 |
7 | 1760mm rewinding machine | 1 |
8 | 1760mm winding machine | 1 |
9 | paper-transducer(Siemens) | 1 |
10 | high-post box | 2 |
11 | pulp-modulating box | 2 |
12 | waste pulp shredder | 2 |
13 | vibrating screen | 2 |
14 | centrifugal screen | 2 |
15 | Thruster | 5 |
16 | 4 inch pulp pump | 5 |
17 | 6 inch pulp pump | 1 |
18 | 606 desander | 6 |
19 | double suction pulp-200 | 1 |
20 | double pumping machine | 3 |
21 | Work table | 1 |
22 | 4T boiler(coal) | 1 |
Packaging Details: straw rope, wooden package
Delivery Details: Within 4 months after receiving the payment
Pre-sales Service:
- offer technical problems consultation
- visit our factory to see finished machines
- optimize the sheme to lower your investment
- negotiate for an appropriate discount
- take equipments quality test before delivery
- offer fast and safe delivery
- assist to establish production line
- send engineers to install and debug equipment
- train first-line operators on site
- regularly visit to help solve production problems
- provide life-long maintenance service
Hey,hello! Interested?
http://zzjinhua.en.china.cn/
Contact us anytime for more details you want to know.
Look forward to recieving your message!
Company Profile
Gongyi Jinhua Machinery Manufacturing Co., Ltd. is a joint venture which mainly produces complete equipment of equipment of pulping and paper machine complete equipment,waste recycling plant,shredder machine,crusher machine,agricultural drying machine .
Our company is located in China's transportation hub in Zhengzhou city, founded in 1980. The production facility covers an area of 8,600 square meters with a construction area of 20,800 square meters. With the management idea of sincerity, after thirty years of continuous development and strength, now we employ over 500 full time staff members with more than 100 professional technicians. We also employ 50 staff members who are translators, salespersons, electronic commerce persons. Our company is an integrated industrial enterprise of scientific research, product development, manufacturing and sale.
Our company has modern management systems, advanced manufacturing technology, complete testing methods, a large number of excellent processing equipment and high-quality skilled workers. All products pass ISO9001:2008 international quality authentication. Our products are sold throughout the world, including Canada,America,South America,Gremany,France,England, Southeast Asia, Bangladesh, Indonesia, Pakistan, Egypt, Syria, Mexico, Nigeria, Russia, etc. Our company wins customers' trust and recognition widely with integrity, pragmatism, refinement development and eternal commitment.
Our company offers an exceptional service team of sale and technology, who offers program and craft process design, technical training and so on. We also offer service of pre-sales, in-sales and after-sales.
