3m Small Pneumatic Camera Pole and Telescopic CCTV Mast

                                             3m small pneumatic camera pole and telescopic CCTV mast

Specifications of pneumatic camera pole

1> Extended height: 3.0m
2>Retracted height: 2.0m
3>Outer diameter:  98mm
4>Loading: 50kg
5>Collar style: non-locking collar
6>Number of sections: 3 sections
7>Mast weight: 25kg approx
8>Max Working pressure:0.25MPA
9>Working temparature:-40--+40C
10>Lifting speed:2.0m per minute

Overview

It can help lamplight, camera, Antenna, mobile and other equipment rise and drop to a predetermined height after its work. It also plays an important role in natural disasters, emergency rescue at night and lightning at the Golf course and large football field.Our product has the advantages of large play load, low noise, fast lifting, strong buffering & stable performance and the like. With high strength aluminum alloy, our products can easily meet the needs of different height and load in different places. It can be installed on the ground or on the vehicle to ensure the application effect.

Application:
Microwave Antenna Masts Tower, Radio Communication Towers, Surveillance Camera Elevation, Sensor Elevation, Data Gathering, Atmosperic Measurement, Airfield Weather Stations, Oil Field Exploration, Border Security Application......

One unit of pneumatic camera pole to be wrapped with Poly tapes and then put into carton

WARRATY PERIOD:

Except the damages due to misuse, unauthorized modification and man-made sabotage, the damaged parts will enjoyed free after-sales maintenance within one year's time from the date of delivery on the condition that the buyer himself will bear the shipping cost back and forth and the said damage should be confirmed by the seller through photos and description.

Installation Instructions:
1)The pneumatic camera pole can be installed on the ground, or on the vehicle. No matter where to install, its installation shall keep vertical with the ground.Tilted telescopic antenna mast will affect the rise and fall of itself, and if the lifting rod tilts seriously or maintain a long time, damage and danger could not be avoided.
2)The pneumatic camera pole needs to be installed on a fixed object, without any shaking, such as walls, car body, or pile. At least two fixed points will be installed, and one point must be installed on the body of the telescopic antenna mast. And the distance between two points should be longer than 2/3 of the height of telescopic antenna mast. Its connection must be solid and reliable.
