1. The features of SPJ-600 water well drilling rig
SPJ-600 water well drilling rig is mainly used for drilling and exploration of hydrology and water wells within 600 meters, which is suitable for soil, rock and gravel layers.
The SPJ-600 water well drilling rigadopts mechanical transmission and rotary table driving drilling tool to achieve footage. It has the characteristics of large output torque, strong lifting ability and wide speed range. The rig has windlass, derrick with truss type "A" type tower or four corner towers. The drilling rig is a bulk structure, with strong decomposition ability and easy transportation. It can also be processed into trailer or vehicle mounted.
2. The specifications of SPJ-600 water well drilling rig
Drilling depth |
600m |
|
Borehole diameter |
500mm-2500mm |
|
Rotary table latus rectum |
605mm |
|
Active drillingpipe |
108*108*12mm |
|
Drilling pipe |
89mm |
|
Rotary speed |
42/75/134kn.m |
|
|
Main windlass |
single rope lifting power |
35kn |
hook rated load |
210kn |
|
hook lifting speed |
0.15-0.47m/s |
|
pulley block model |
3*3 |
|
wire-rope diameter |
20-21.5mm |
|
Assistant windlass |
single rope rated lifting power |
15kn |
maximum lifting power of a single rope |
20kn |
|
single rope rated lifting speed |
0.58m/s |
|
wire-rope diameter |
9.8mm |
|
Windlass power |
37kw |
|
Gross weight (excluding drillingpipe) |
11t |
|
