SPJ-1000 Water Well Drilling Rig

FOB Price

US$ 1000 - 10000 / Set

1 Set(Min. Order)

Port QINGDAO
Payment TermsT/T L/C

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HUAXIA MASTER	Place of Origin	China
Type	Rotary Drilling Rig	Certification	ISO9001
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	6 months
Power Type	Diesel	Usage	Coal
Condition	New

Product Description

The features of SPJ-1000 water well drilling rig

is mainly used for drilling and exploration of hydrology and water wells within 1000 meters, which is suitable for soil, rock and gravel layers.

The SPJ-1000 water well drilling rig adopts mechanical transmission and rotary table driving drilling tool to achieve footage. It has the characteristics of large output torque, strong lifting ability and wide speed range. The drilling rig has windlass, derrick with truss type "A" type tower or four corner towers. The drilling rig is a bulk structure, with strong decomposition ability and easy transportation. It can also be processed into trailer or vehicle mounted.

2.The specifications of SPJ-1000 water well drilling rig

Drilling depth	1000m
Borehole diameter	500mm
Rotary table diameter	1200mm
Rotary table latus rectum	670mm
Rotary table weight	2050kg
Rotary speed	36/60/90/130r/min
Active drilling pipe	13313312mm
Drilling pipe	89mm or114mm
Main windlass	single rope lifting force	60t
Assistant windlass	single rope rated lifting force	30t
Windlass power	45kw
