China great selling 3 axis 4 axis 5 axis auto tool changing 1325 ATC cnc router machine for woodworking
1.Main Features for our 4 axis CNC router |
|
1.1 HSD spindle ----original famoue brand from Italian,also can choose Kolumb spindle 1.2 SYNTEC control system------It is from Taiwan with high performance and competitive price 1.3 Yaskawa servo motor and drives----They are from Japan with high precision and long life 1.4 HIWIN linear guide ------ made from Taiwan,used for linear reciprocating stadium 1.5 Working area:1300*2500*400mm C Rotary Axis:360o 1.6 Whole cast steel structure thicken to 8mm 1.7 Drive System: X,Y-Rack Z-Ball Screw,Z with high precision ball screw 1.8 Automatic Tool Calibration - ----To guide rail and slide block , make it run better 1.9 Schneider electrical components - ----original brand from France 1.10 Japanese Omron Switch with long life 1.11 APEX Reudcer from Taiwan----More powerful and higher precision 1.12 T-Slot table with Aluminum sheel - -----Use clamp fixed materials |
2.Specifications for 4 axis CNC router |
1 |
Model |
MM- 1325 |
MA-1530 |
MA-1836 |
MA-2030 |
MA-2040 |
2 |
X,Y Working Area |
1300x2500mm |
1500x3000mm |
1800x3600mm |
2000x3000mm |
2000x4000mm |
3 |
Z axis travel |
200mm-700mm(according to your requests) |
||||
4 |
Table Surface |
Vacuum and T-slot Combined(double use) |
||||
5 |
Frame |
Thicken steel Square Tube Heavy structure ,15mm thicken steel gantry with T type |
||||
6 |
X, Y Structure |
Helical Gear and rack transmission, Taiwan HIWIN Linear Rail |
||||
7 |
Z Structure |
Taiwan TBI Ball Screw, Taiwan HIWIN Linear Rail |
||||
8 |
Spindle Power |
China top brand Water cooling spindle / Italy HSD Air cooling spindle |
||||
9 |
Spindle Speed |
0-24000RPM / 0-18000RPM |
||||
10 |
Drive Motors |
Stepper Motor Driver/ Servo Motor Driver |
||||
11 |
Working Voltage |
AC220V/380V 1PH/3PH 50/60Hz, |
||||
12 |
Command Language |
G Code |
||||
13 |
Operating System |
Mach3 / NCstudio / DSP / Taiwan SYNTEC control system |
||||
14 |
Computer Interface |
USB port |
||||
15 |
Flash Memory |
512M |
||||
16 |
Collet |
ER20/ER25/ER30 |
||||
17 |
Inverter |
China top brand Fuling inverter / Taiwan Delta inverter |
||||
18 |
Software Compatibility |
Type 3 /Artcam |
||||
3.Detailed Images for your reference |
|
------Main Parts of CNC router
|
4.Application indutry and materials of cnc router |
1) Mould: wood,wax, wood, gypsum,foams,wax |
4.Certifications of Mingmei CNC Machinery |
|
We Will Provide You The Professional Service Do Not Hesitate To Contact With Me.
|
What we can do for customers? |
Trade Asssurance |
How about the Packing&Delivery? |
|
Packaging:These machines will be packed with Plastic Film and standard export wooden case, to make sure customer will receive the machines they ordered Intact. Shipping:Shipping by 20GP,40GP,40HQ Container...
According to Customers’ location and the vehicle size , we will provide professional packaging can save sea freight for cutomers. |
Shandong Mingmei CNC Machinery Co., Ltd |
|
MMCNC was found in 1995,which is a modern private enterprise specialized in technology development,machinery manufacture and product sales.Company cover an area of 70000 square meters and 200 staffs. MMCNC machine include Processing machine for making aluminum PVC window and door as well as curtain wall, such as--- Double head Cutting Saw;Corner Crimping Machine;End miller;Copy router;PVC Welding Machine;Corner Cleaning Machine; we also produce CNC Router etc.which these machine have got CE,ECM,EEC authorization .and it has won good market reputation.
Thank you for your interest in our products, we welcome new and old customers contact us for future business relationships and achieving mutual success! |
Company&Plant |
|
Exhibition-Shanghai,Beijing,Guangzhou... |
|
Clients Visit |
|
