window door cnc machine cutting drilling machine , cnc aluminum machine

Features

1. This machine is designed for processing round holes, slots, keyhole etc on aluminum profile, window door and curtain wall industry,it is also suitable for processing milling, chamfering, engraving plane surface and other procedure.

2. Main spindle adopt air-cooling electric main axis, 3kw power, 0-1800r/min,have the function of high precision, high safety and high reliable.

3. Adopt Taiwan SYNTEC CNC control systerm.Have professional CAD-CAM programming software.It can transform processing G code automatically,have the function of easy operation, high efficiency and lower labor intensity.

4. Imported guide rail, sliding block,X axis adopt high precision oblique gear and rack driving. Y and Z adopt high precision ball screw drive. The drive is stable, so can improve the precision of whole machine.

5. The worktable can overturn180°. -90°~0°~+90°. Clamping one time profile can realize three faces processing. When processing deeply hole(hetero type hole), it can realize deeply hole processing through overturn worktable, so can highly improve processing efficiency.

6. Adopt manual pump oil supply system,blades adopt system control spray cooling device.

7. The main electric parts:circuit breaks, AC contactor are all SCHNEIDER brand.

8. The main components adopt steel structure and they are all through aging treatment.

  Machine video link:        /watch?v=ja88Dr5_qVM

 Applications Field

    This machine is designed for processing round holes, slots, keyhole etc on aluminum profile, window-door and curtain wall industry, it is also suitable for processing milling , chamfering, engraving plane surface and other procedure.

    Suggestion:  We can produce products according client needs,such as:size, outside view, configuration etc.

Technical Parameters

 Detailed Images of 3+1 Axis CNC Processing Center for Aluminum Profile

1. SYNTEC control system------It is from Taiwan with high performance and competitive price.

2. Delta servo motor and drives----They are from Taiwan with high precision and long life.

3. DELTA-VFD-B inverter ------it is from Taiwan with high quality.(CE and UL authentication)

4. Schneider electrical components - ----original brand from France.

5. HSD spindle -9kw----original famous brand from Italian,also can choose Kolumb spindle

6. Tools magazine ------ 6 sets tools,the handle is approved ISO30 standards.

7. Z-axis adopts TBI Ball screw from Taiwan------high precision and long life

8. The worktable can overturn180°. -90°~0°~+90°.------ Clamping one time profile can realize three faces processing.
