China Supplier Jinan SINON UPVC Window Door Making Machinery
Double Head Cutting Saw
Machine Features
1. Double Head Cutting Saw for PVC Window Door
2. Cut cut 45°,90°and 135° , angle adjust by manual.
3. The movable saw head moved by motor drive,easy and convenient operate.
4. Saw lade rotates smoothly due to high accurate main spindle box,steady running with high precision.
5. Install the mullion cutting device,more convenient and accurate.
6. Dust collector is optional according to customer's requirement.
Technical Specification | |
Name |
UPVC Window Door Making Machinery for Cutting |
Model |
SSJ06-450x3700 |
Power Supply |
380V/50Hz |
Input Power |
2*1.5kw |
Motor Rotation Speed |
2800r/min |
Air Working Pressure |
0.5-0.8MPa |
Blade Specification |
450mm*30mm |
Cutter Feeding Speed |
0-3m/min |
Cutting length |
450-3700mm |
Cutting width |
Max120mm |
Cutting height |
45°165mm ; 90°200mm |
Cutting angle |
45°,90°,135° |
Cutting profile surface plane |
≤ 0.15mm |
Cutting profile surface |
Ra12.5µm |
Dimension(L*W*H) |
4500*1200*1500mm |
Weight |
1000KG |
Professional Customization and Solution for PVC Window and Door Production Machine
Related Machines for PVC Window Door
China Supplier Jinan SINON UPVC Window Door Making Machinery
SINON - is well-known manufacturer of UPVC / Aluminum Window Door Making Machines, Industrial Aluminium Processing Machines. is one of the most professional company in the industry. SINON was founded in 2003, has more than 10 years of rich experience. the company production assembly workshop of 5000 square meters, mechanical processing workshop, sheet metal workshop 2000 square meters. As a professional research and development, manufacturing, sales and service team of innovative enterprise, the company's products cover PVC doors and Windows and aluminum doors and Windows equipment two major series of hundreds of products, has more than 20 technical patents,
around 2010, the company was one of the best companies manufacturing UPVC plastic material cutting center, UPVC doors and Windows cleaning welding automatic production line, aluminum cutting center, four head corner combining machine. In 2012 developed china’s first aluminum profile 4-axis CNC milling machine, 2015 developed China's first manufacturing sun room doors and Windows of large cross section of CNC double cutting saw, first developed CNC corner cutting center that can cut more than 10 yards. And apply for the two national invention patent.
Sinon company successively passed the ISO9001 international quality certification system and the European Union CE safety certification and the United States UL safety certification,
Our products are exported to more than 40 countries and regions, Central and Eastern Europe ,Middle East & North Africa,Southeast Asia ,North and South America we warmly welcome all customers come to jinan,come to Sinon company to visit, negotiate and cooperate.
China Supplier Jinan SINON UPVC Window Door Making Machinery
1. Are you a trading company or a factory?
Factory and Trade ( integration)
2. When can we arrange shipment?
We usually arrange shipment within 15 days after getting deposit,
but customized machines should be more than 25 days.
3. Do you provide equipment operation training after sale?
Yes. We can send professional engineers to the working site for equipment installation, adjustment, and
operation training. All of our engineers have passport.
4. If I make Aluminum window and door, how many basic machines do I need?
1).Double /Single-head cutting saw
2). Copy routing machine
3).End milling machine
4).Corner connector automatic cutting saw
5).Corner combining machine
6).Punching hole machine
5. If I make PVC window and door, how many basic machines do i need?
1).Double /Single-head cutting saw
2). Welding machine
3).Glazing Bead saw machine
4).Water-slot Milling machine
5).End Milling machine
6).Lock hole Milling machine
7).Corner cleaning machine
6. Can you customize the machine according to my request?
Yes. We have experienced engineers and technical team, can provide personalized service
If you have any questions,please don't hesitate to contact us !
