Four Head Welding PVC Window Door Fabrication MachineUS$ 3,500 - 4,500MOQ: 1 Set -
UPVC Window Single Head Plastic Window Welding Making MachineUS$ 1,200 - 1,600MOQ: 1 Set
-
Arbitrary Angle Single Head Welding Machine for PVC Window DoorUS$ 1,800 - 3,000MOQ: 1 Set
-
Jinan Sinon Machine PVC Window Door V Cutting SawUS$ 800 - 1,000MOQ: 1 Set
-
PVC Window Door UPVC Window Corner Seam Cleaning MachineUS$ 4,000 - 6,000MOQ: 1 Set
PVC Window Double Head Cutting Saw PVC Window Making Machine
SSJ07-450x3600
Product features
1.PVC Window Double Head Cutting Saw ,PVC Window Making Machine
2. Angle range: 45°, 90° and any angle among 45° ,90°, angle automatic indexing.
3. Saw blade rotates smoothly due to high accurate main spindle Motor, steady running with high
precision
4. Adapting digital display ruler to realize the digital display location as needed, Cutting size display at the LED screen. Cutting size is accurate and intuitive.
5. With standard short size cutting device(manual). It’s easy to cut small material, so that ensure cutting precision.
6. With dust collector to protect the health of operator.
7. Equipped with phase sequence protection device, so as to protect the machine once shut off or disconnect the phase.
Detail Display
Technical specifications | |
Name |
PVC Window Double Head Cutting Saw PVC Window Making Machine |
Model |
SSJ07-450x3600 |
Air Pressure: |
0.5-0.8MPa |
Air Consumption |
50(L/min) |
Input Voltage |
50Hz 380/220V or As Customer required |
Input Power |
2*1.5 (Kw) |
Saw Blade Diameter |
Φ 450 |
Motor Rotary Speed |
2800(r/min) |
Feeding Speed |
0-3m/min |
Cutting Width |
120(mm) |
Cutting Length |
200-3600mm |
Overall Dimension: |
4400mm*1200mm*1500mm |
Weight: |
1200(kg) |
Main Accessories | |
AC Contactor & Breaker |
Schneider, France |
Air Cylinder |
SMC ,Japan |
Magnetic Valve |
SMC ,Japan |
Professional Customization and Solution for Aluminum & UPVC Window Door Production
PVC Window Making Machine
PVC Window Making Machine Service
1. Detailed and professional User Manual and operation video
2. one year warranty since B/L issued,lifetime maintenance
3. our engineers could provide service overseas for installation,test and training
4. 24h service online by E-mail, calling ,social media ,video call
5. broken parts can be changed quickly, some parts can sent FREE within one year
6. Return visit for free maintenance.
PVC Window Double Head Cutting Saw PVC Window Making Machine
Jinan SINON CNC Machine Co., LTD
is China's well-known Aluminum and Plastic Window Door Manufacturing Machine manufacturer. is one of the most professional company in the industry. SINON was founded in 2003, has more than 10 years of rich experience. the company production assembly workshop of 5000 square meters, mechanical processing workshop, sheet metal workshop 2000 square meters. As a professional research and development, manufacturing, sales and service team of innovative enterprise, the company's products cover PVC doors and Windows and aluminum doors and Windows equipment two major series of hundreds of products, has more than 20 technical patents,
around 2010, the company was one of the best companies manufacturing UPVC plastic material cutting center, UPVC doors and Windows cleaning welding automatic production line, aluminum cutting center, four head corner combining machine. In 2012 developed china’s first aluminum profile 4-axis CNC milling machine, 2015 developed China's first manufacturing sun room doors and Windows of large cross section of CNC double cutting saw, first developed CNC corner cutting center that can cut more than 10 yards. And apply for the two national invention patent.
Sinon company successively passed the ISO9001 international quality certification system and the European Union CE safety certification and the United States UL safety certification,
Our products are exported to more than 40 countries and regions, Central and Eastern Europe ,Middle East & North Africa,Southeast Asia ,North and South America we warmly welcome all customers come to jinan,come to Sinon company to visit, negotiate and cooperate.
1. Are you a trading company or a factory?
Factory and Trade ( integration)
2. When can we arrange shipment?
We usually arrange shipment within 15 days after getting deposit,
but customized machines should be more than 25 days.
3. Do you provide equipment operation training after sale?
Yes. We can send professional engineers to the working site for equipment installation, adjustment, and
operation training. All of our engineers have passport.
4. If I make Aluminum window and door, how many basic machines do I need?
1).Double /Single-head cutting saw
2). Copy routing machine
3).End milling machine
4).Corner connector automatic cutting saw
5).Corner combining machine
6).Punching hole machine
5. If I make PVC window and door, how many basic machines do i need?
1).Double /Single-head cutting saw
2). Welding machine
3).Glazing Bead saw machine
4).Water-slot Milling machine
5).End Milling machine
6).Lock hole Milling machine
7).Corner cleaning machine
6. Can you customize the machine according to my request?
Yes. We have experienced engineers and technical team, can provide personalized service
PVC Window Double Head Cutting Saw PVC Window Making Machine
