PVC Profile Window Door Double Heads Auto Water-Slot Routing Machine Pvc Profile Hole Drilling Machine
US$ 1,869 - 2,363.4
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
SINON
Model Number:
SCX03-3*60
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdoao shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PLC Controller Screw Drilling Machine With High Quality and Best ServiceUS$ 2,300 - 3,200MOQ: 1 Set -
UPVC Profile Frame Window and Door Four Heads(Four Corner)Vertical Welding Corner Crimping Machine With CNC (Automatic)US$ 3,885 - 4,591MOQ: 1 Set
-
2016 Hot Sale Sealed Cover Milling Machine of Sliding Window Sash for PVC ProfileUS$ 420 - 520MOQ: 1 Piece
-
Upvc Double Head Seamless Automatic Welding Machine for Window and DoorUS$ 8,336 - 9,852MOQ: 1 Set
-
PVC Profile Single Head Automatic Screw Fastening Equipment PVC Window MachineUS$ 2,530 - 3,000MOQ: 1 Piece
Brand Name
SINON
Model Number
SCX03-3*60
PVC Profile Window Door Double Heads Auto Water-Slot Routing Machine pvc profile hole drilling machine
Feature:
- Professional use in milling the water slot and balanced holes of air pressure of window and door in PVC profile
- Adopt advancing Germany technique. The modularization structure design, there are three milling heads which can be freely selected working in individually or combined, easy to operate.
- Sliding and turret clamp buffers allow quick adjustment.
- Auto moving working table ensure nice milling
- Easy adjustment to realize symmetrical milling.
Optional:
- Two-head milling model SCXZ2-60*120*3000
Technical Specifications
Air Pressure: | 0.5-0.8MPa |
Air Consumption | 30(L/min) |
Input Voltage: | 220V 50Hz Customer specification |
Input Power: | 1.14kW |
Diameter of milling cutter | Φ4*50/75mm Φ5*50/75mm or Customer Specification |
Spindle Rotary Speed: | 26000(r/min) |
Slot Depth | 30(mm)(Max) |
Slot Length: | 30~60(mm) |
Overall Dimension: | 1950×860×1600(mm) |
Weight: | 280(kg) |
