Muti-function Project Laser Diastimeter
Item No: LH-D1600AH LH-D2000AH
Advantage:
1. Long Distance Measure: High Reflectance Object can reach to 2000m (maximum);
2. High Accuracy: Accuracy can reach to 0.3m within 200m;
3. With Out-fixed LCD Screen: Easily Handling;
4. High Penetrate LCD, can be even used after dark.
Specification
ITEM NO |
LH-D1600AH |
LH-D2000AH |
MEASURE DISTANCE |
5-1600M |
5-2000M |
ONE-TIME MEASURE |
√ |
√ |
SCAN MEASURE |
√ |
√ |
HEIGHT MEASURE |
√ |
√ |
ANGLE MEASURE |
√ |
√ |
HORIZONTAL MEASURE |
√ |
√ |
ALTITUDE INTERCEPT |
√ |
√ |
FLAG MEASURE MODE |
× |
× |
PENETRATE MODE |
× |
× |
OUT-FIXED SCREEN |
√ |
√ |
DATA STORAGE |
√ |
√ |
CHARGEABLE |
√ |
√ |
TRIPOD SCREW HOLES |
√ |
√ |
MEASURE ACCURACY |
±0.3m（、±0.3m-1m(>200m） |
|
RESULT DISPLAY |
INNER LCD & OUT-FIXED LCD |
|
MAGNIFICATION TOMES |
7.0X |
|
OBJECTIVE DIAMETER |
Φ26mm |
|
FILED |
6 DEGREE |
|
WORKING TEMPERATURE |
﹣10~＋50℃ |
|
LASER TYPE |
905nm， FDA CLASS1 |
|
LASER EYE SAFE |
√ |
√ |
FOCUS TYPE |
FOCUS BY LENS |
|
ELECTRIC POWER |
INNER 1200MA/H CHARGEABLE LITHIUM BATTERY |
|
DIMENSION |
126*79.5*44mm |
|
NET WEIGHT |
246g |
|
