Semi-automatic pneumatic metal angle cutting machine
- 200 Set / Sets per Month
- ShenZhen/GuangZhou
- T/T Credit Card
You May Like
Product Details
| Brand Name | Chine Chern | Model Number | JC-275-2A |
Product Description
Features:
1. Two-way clamp sawing will make the surface smooth, without burrs. The cutting precision is much more higher than before.
2. Sawing angle:(left) 90°~0°,(right)90°~45°.
3. Automatic loops cooling system enables the smoothness of the cut surface
4. Applicable sawing material: stainless steel, steel tube, carbon steel, iron. The furniture field, sports equipment, highting industries are also available.
5..Vertical slideway for advance and retreat blade up and down.Cutting feed is steady and cutting tools are of long use life.High precision of saw cutting.
6.Equipped with electric saw protection device.
7. Cutting centralism processing, maintenance is easy.
8.Sawpieces are centralized for disposal which is convenient and clean.
9. The clamping and cutting adopts pneumatic type.
Main technical parameter:
| Model | JC-275-2A | ||
| Head rotating angle | 90° | 45° | |
| Cutting capacity area | Solid bar | 38mm | 30mm |
| Round tube | 85mm | 75mm | |
| Angle steel | 75×75mm | 50×50mm | |
| Square tube | 75×75mm | 75×75mm | |
| Through-shaped steel | 75×75mm | 50×50mm | |
| Retangular steel | 75×90mm | 75×60mm | |
| Host motor | 2.4KW/2.0KW-2/4P | ||
| Spindle speed | RPM120/60 | ||
| Cooling pump | 1/8HP | ||
| Compressed Air pressure | 4-6kg/cm2 | ||
| Saw blade(Diameter) | 250mm-300mm | ||
| Feeding length | 3-650mm(Standard),can feed three times,total 1950mm | ||
| Machine weight(KG) | 220KG | ||
| Machine size(L×W×H) | 850×610×1350 | ||
| Standard fittings | HSS Saw blade 250mm | ||
| HSS Saw blade ,One scale,one tool box ,One set of clamping module | |||
ISO certificates:
We welcome you to contact us for more information and look forward to working with you!
We will be a reliable and strong supplier in China.
