atomatic cnc double glazing production line machine/CNC Double Glass Making Machine
Model: IGV25-S
Features:
1. This machine has self-diagnose system, easily check the error.
2. It can identify the Low-E glass and coating glass automatically. So it can stop the first hard brush automatically protecting the glass from scratching.
3. The PLC and proximity switch adopt OMRON imported for Japan.
4. It has high precision and works steadily. Because we adopt the screw and flat press.
5. Servo driver and servo motor imported from YASAKWA Japan can control glass-combining precisely.
6. This machine adopts inverter control transmission motor. So it can easily slow down and accelerate.
7. It can produce big and small scale, tri-glass and insulating glass(Optional)
Parameters:
Voltage: | 380V 50HZ |
Power: | 29.5KW |
Air consumption: | 160L/min |
Max. process dimension: | 2500mm x 5000mm |
| Min. process dimension: | 250mm x 450mm |
| Max. thickness: | 40mm |
| Convey speed: | 12-40m/min |
| Cleaning speed: | 8-12m/min |
| Max. processing speed: | 40m/min |
| Overall dimension: | 22800x2800x3400mm |
Other Double Glazing Machines:
Factory:
Samples:
Exhibitions:
Factories of Customers:
Customers Visit:
Parker Service Team:
Packing & Loading:
JINAN PARKER MACHINERY Co.,LTD
Website: ;
Contact: Linda
Cell: 0086-182-5416-1395
Skype: lindaredouble
Email: linda
