Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS

Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-1
Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-2
Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-3
Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-4
Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-5
Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-6
Aluminium Profile Double Head High Spend 3-axis CNC Machining Center DMCC3-2HS photo-7
US$ 103,000 - 103,000 MOQ: 1 set
Key Specifications
Get Latest Price
Brand Name:
PARKER
Place of Origin:
Shandong, China
Type:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name PARKER
Place of Origin Shandong, China
Type Horizontal
Certification CE SGS
Warranty 1 Year
Weight 11000kg
Dimension(L*W*H) 6000*3100*2800mm
Voltage 380V/50Hz
Condition New
Power(W) 30KW
Product Description

FUNCTION
1, Integrated machine structure of grade Q235A steel, with annealing and aging treatment, which ensures complete machine of high stability.

2,Integrated design of electrical cabinet and machine body makes transportation , installation ,operation much easier,and the stability more higher.

3, LH/RH - the left and right clamps , including corresponding fixtures are interchangeable, clamps in different positions are also interchangeable.

4, Equipped with chain type chip removal system, easy for cleaning, and adopts oil-water separator, which can separate lubrication oil and water automatically.

5, It's high efficient with double heads and double –position processing.

6, X, Y, Z axis max. positioning speeds can reach up to 56M, 30M, 30M / min.

7,Equipped with Taiwan OBRAUN CNC Turning Table configured as the fourth axis. The positioning precision is within 20 arc seconds and the maximum limit approach 0 degree space, which greatly improved the processing precision and can achieve 360 degrees processing at one time clamping.

8, Clamps are equipped with switches, the pressure gauge and regulator make clamps adjustable and visible, human-friendly design, easy to operate, prevent the loosening of profiles to the maximum extent .

9, Full protection for cables, guide rails, racks and screws, effectively prevent fragments inside during processing, and greatly improve lifetime of these spare parts.

10, Equipped with automatic lubrication system for rails, which is convenient for maintenance.

Product Name
Aluminium profile double head high spend 3-axis CNC machining center
DMCC3-2HS
Stroke for X axis
3500mm
Spindle Speed
12000 RPM
Capacity Of Tools Magazine
16*2
Tool Change Time
3.0s
X Axis Moving Speed
52m/min
X/Y/Z Feeding Speed
0~2000mm/min
Serve Motor
FANUC
Air Pressure
0.5MPa – 0.8MPa
Spindle
CELL
Electrical Parts
Schneider
Products Show
Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Company Introduce

                                                                 PARKER Introduce

*PARKER Machinery Co.,LTD was founded in 2003,since the entry into the window door curtain wall machinery manufacturing field,peck with the best team and most stringent manufacturing standards,has been committed to the global supply of machinery and the best service.Today,with more than 300 employees,PARKER Industrial Park covers an area of 70000 m^2,Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.

*PARKER products include aluminium,PVC window and doors machinery,aluminium curtain wall processing machinery,industrial aluminium processing machinery and insulating glass series production line machinery.

*PARKER machinery expotrs to the world more than 80 countries and regions,and has firstly established branches in USA,India,UAE,Brazil,has more than 15 patents.

*PARKER machinery are all passed through high standard European CE certification,American UL certification and Canadian CSA certification.

*PARKER manufacturing creates ecological management system of 9M that is unique and most proud of,and the human resources,raw materials,technology methods,environment,information etc. Have been ongoing ascension,and improves the overall quality and core competitiveness of parker.Customers around the world are actively popularize and apply it,benefit a lot from it.

*PARKER machine core parts procurement achieved internationalization,and established a cooperative partnership with ABBA,OMRON,SCHNEIDER,OPTIMA.

*PARKER people are always follow the core concept,it is "PARKER is developing with the world",it is PARKER peoples' strict implementation of ecological system of PAREKR and of "zero defect" stern pursuit,which makes the PARKER machine perfect implement unique global standard,achieves improvement value and sustainable innovation!

*PARKER machinery,leads the era of intelligence,create the strategy of globalization!

*PARKER machinery,contribution to the world culture of windows and doors!

                                                       PARKER Cooperative Partner

Customer Photo
Packing & Delivery
1. Special logistics packaging
2. Suitable carton size
3. Shock bubble film
4. Professional placement
5. Professional shock
6. Complete package
