DMCC3 Aluminum Curtain Wall Machine 3 Axis Syntec System Cnc Machining Center From China
Company Introduction
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
Aluminium Curtain Wall Profile Machine Center Features
1.The Machine is suitable for processing installation holes ,water slot,shaped holes and end milling and making screw on curtain walls and aluminum windows and doors.
2.It adopts high-speed electric principal axis,which is imported from Italy.It’s extremely efficent and can swing in +-90 Angle
3.It adopts high-quality computer control system which is used in industry area specially,with good user interface,graphical programming and processing tracking interface,truly realize what you see and what you get.
4.It adopts high-quality servo motor,ball screw,linear guide pair and bearing and so on to ensure the machine runs with high precision.
5.Equipped six cutters positions,the cutter can change quickly and automatically.
6.The semi-closed guard improved security greatly
7.Clamping device position can be optimized and put to right position automatically and freely.
Aluminium Curtain Wall Profile Machine Center Parameters
| STROKE | ||
| Stroke for X axis | 7200mm | |
| Stroke for Y axis | 400mm | |
| Stroke for Z axis | 400mm | |
| SPINDLE | ||
| Spindle Speed | 11000 RPM | |
| TOOLS | ||
| Tools Changer Format | Turret type | |
| Capacity Of Tools Magazine | 6 PCS | |
| Tool Change Time | 3.0s | |
| MOVING SPEED Fanuc system Germany PA system | ||
| X Axis Moving Speed | 52m/min 80m/min | |
| Y Axis Moving Speed | 30m/min 60m/min | |
| Z Axis Moving Speed | 30m/min 60m/min | |
| X/Y/Z Feeding Speed | 0~2000mm/min | |
| POWER OF MOTOR | ||
| Spindle Driven Motor | 5.5KW | |
| X/Y/Z Driven Motor | 1.8KW, 1.8KW ,1.8KW | |
LUBRICATING SYSTEM | |
| Lubricating System | SAGELY |
| Cooling System | Bijur |
| PRECISION | |
| Position Precision Of X/Y/Z Axis | ±0.02mm |
| Repeating Position | ±0.02mm |
| SIXE OF MACHINE | |
| Power Supply | AC 380V 50Hz |
| Total Power | 13 KW |
| Air Pressure | 0.5MPa~0.8MPa |
| Weight | 5T |
| Dimentions | 9900mm×2350mm×2560mm |
| MAIN COMPONENT CONFIGURATION | |
| Operation System | Japan FANUC,Germany PA |
| Serve Motor | FANUC, YASKAWA |
| Spindle Motor | FANUC,Beijing CTB |
| Spindle | Italy HSD |
| Tools Magazine | Taiwan DERA |
| Guide Rails | Japan THK |
| Bearings | Japan NSK |
| Ball Screw | Taiwan TBI |
| Electrical Parts | France Schneider |
| Pneumatic Components | Taiwan AIRTAC,Japan SMC |
| Reducer | Taiwan ATG |
Aluminium Curtain Wall Profile Machine Center Detail pictures
Samples
Service
Package and delivery
Factory
