Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale

Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale thumbnail-1
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale thumbnail-2
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale thumbnail-3
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale thumbnail-4
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale thumbnail-5
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale photo-1
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale photo-2
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale photo-3
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale photo-4
Gold Concentrator, Coal Mine Feeding Disk Feeder Equipment Machine for Sale photo-5
US$ 1000 - 23000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
ZKCORP
Place of Origin:
China
Model Number:
DB4
Contact Supplier Request Quote Chat Now
Henan Nongyi
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ZKCORP
Place of Origin China
Model Number DB4
Certification CE,ISO
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1 Year
Weight 1t
Power Type Diesel
Application Gold concentrator, coal mine, chemical plant, construction
Condition New
Power(W) 0.75-1KW
Capacity(t/h) 1-30m3h

Introduction

Disk feeder is a cubage measuring feeding equipment; it supplies materials to the next procedure evenly and continuously; at the same time, it can bear relatively higher pressure. It is widely used in gold concentrator, coal mine, chemical plant, construction and foundry for quantitative and even feeding.


Application

This feeder is positive displacement feediing equipment. It can feed the material to next process evenly and continuously. It is suitable for the non-viscosity material, and the flow type powder material. It is for the material such as ore, coal powder, cement, clinker, limestone, clay powder etc

Featurers:

1.Least chance of materials being destroyed in the process of feeding.

2.Continuous feeding of materials that are not uniform in size and shape.

3.Less drive power

4.Air-tight construction is feasible.

5. Applicable to large size silo at large feed rate.


model and  spec

disk dia(mm)

capacity(m3/h)

disk rev(r/min)

feeding size(mm)

motor



model

power(kw)

DB4

400

0.19-1.32

10

15

Y90S-6

0.75

DB6

600

0.69-3.9

8

25

Y90L-6

1.1

DB8

800

1.18-7.65

8

30

Y90L-6

1.1

DB10

1000

2.59-16.7

7.5

40

Y100L-6

1.5

DB13

1300

4.19-27.8

6.5

50

Y132L-6

3.0


If you want to know more,please contact me.

Email:ec03@zkcorp.com

WhatsApp: 008618937185591
