Help CenterTobee® 18/16TU-AH Mining Horizontal Slurry Pump
Related Products
-
Tobee® 16/14TU-AH Rubber Slurry Pump AUUS$ 800 - 2000MOQ: 1 Piece -
Tobee® 14/12ST-AHR Rubber Slurry PumpUS$ 800 - 2000MOQ: 1 Piece
-
Standard 2/1.5 B- AH Horizontal Mill Slurry Discharge PumpUS$ 800 - 2000MOQ: 1 Piece
-
Tobee® 10x8 G - AH Bi-metal Slurry PumpsUS$ 800 - 2000MOQ: 1 Piece
-
Tobee® TSJ Paper Pulp Pump Used in Paper Making Industry Amd Bioethanol IndustriesUS$ 1000 - 3000MOQ: 1 Set
Size: 18" x 16" Capacity: 2160-5040m3/h Head: 8-66m Speed: 200-500rpm NPSHr: 4.5-9m Eff.: 80% Power: Max.1200kw Handling solids: 135mm Materials: R08, R26, R55, S02, S12, S21, S31, S42 etc
18/16TU-AHR Rubber Lined Slurry Pump is standard heavy duty slurry pumps which designed for the continuous pumping of highly abrasive,high density slurries with minimal maintenance requirements,18/16 slurry pump maintains high efficiencies over the wear life of its components.This type of pump typically used in process plant transfers, wet waste processes, recycling-washing plants,sand plant duties, heavy minerals processing, mineral recovery and chemical process plant.
Design Features:
√ Bearing assembly – a large diameter shaft with short overhang minimizes deflection and contributes to long bearing life. Only four through bolts are required to hold the cartridge type housing in the frame.
√ Liners - easily replaceable liners are bolted, not glued, to the casing for positive attachment and east of maintenance. Hard metal liners are completely interchangeable with pressure moulded rubber.
√ Elastomer seal rings back all liner joints.
√ Casing – Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.
√ Impeller – front and rear shrouds have pump out vanes that reduce recirculation and seal contamination. Hard metal and moulded rubber impellers are completely interchangeable.
√ Cast in impeller threads require no inserts or nuts. High efficiency and high head designs are also available.
√ Throatbush – wear is reduced and maintenance simplified by the use of tapered mating faces to allow positive accurate alignment during assembly and simple removal.
√ One-piece frame – a very robust one-piece frame cradles the cartridge type bearing and shaft assembly.
√ An external impeller adjustment mechanism is provided below the bearing housing for easy adjustment of impeller clearance.
