Help CenterTobee® TH20x18 Mill Discharge Pump
Related Products
-
Tobee® TH18x16 Tailings Slurry PumpsUS$ 800 - 2000MOQ: 1 Piece -
Tobee® TH16x14 Minerals Slurry PumpUS$ 800 - 2000MOQ: 1 Piece
-
Tobee® 10x8R-M Medium Duty Slurry Pump-www.slurrypumpsupply.comUS$ 800 - 2000MOQ: 1 Piece
-
Tobee® 8x6S-HH High Head Slurry Pump-www.slurrypumpsupply.comUS$ 800 - 2000MOQ: 1 Piece
-
Tobee® 6x4F-HH High Head Slurry Pump-www.slurrypumpsupply.comUS$ 800 - 2000MOQ: 1 Piece
SPECIFICATIONS:
Size: 20" x 18"
Capacity: 2520-5400m3/h
Head: 13-57m
Speed: 200-400rpm
NPSHr: 5-10m
Eff.: 85%
Power: Max.1200kw
Handling solids: 140mm
Seal arrangement: Packing seal, Expeller seal, Mechanical seal
Materials: High chrome alloy, Rubber, Polyurethane, Ceramic etc
Tobee® TH20x18 Mill Discharge Pump is world’s standard for heavy duties application. It is designed to easily manage large size particles in dense abrasive slurries and offers the right combination of ruggedness, durability, hydraulics and materials. From the most difficult mill discharge to water flushed crusher, From cyclone feed to regrind, flotation and tailings, The 20x18 slurry pump is the best choice.
Design Features:
• Bearing assembly - a large diameter shaft with short overhang minimizes deflection and contributes to long bearing life. Only four through bolts are required to hold the cartridge type housing in the frame.
• Liners - easily replaceable liners are bolted, not glued, to the casing for positive attachment and east of maintenance. Hard metal liners are completely interchangeable with pressure moulded elastomer.
• Elastomer seal rings back all liner joints.
• Casing - Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.
• Impeller - front and rear shrouds have pump out vanes that reduce recirculation and seal contamination. Hard metal and moulded elastomer impellers are completely interchangeable.
• Cast in impeller threads require no inserts or nuts. High efficiency and high head designs are also available.
• Throatbush - wear is reduced and maintenance simplified by the use of tapered mating faces to allow positive accurate alignment during assembly and simple removal.
• One-piece frame - a very robust one-piece frame cradles the cartridge type bearing and shaft assembly.
• An external impeller adjustment mechanism is provided below the bearing housing for easy adjustment of impeller clearance
Tobee® TH20x18 Mill Discharge Pump Performance Parameters:
| Model |
Max.Power (kw) |
Materials | Clear water performance |
Impeller Vane No. |
|||||
| Liner | Impeller |
Capacity Q (m3/h) |
Head H (m) |
Speed n (rpm) |
Eff. η (%) |
NPSH (m) |
|||
| TH20x18TU | 1200 | M | M | 2520-5400 | 13-57 | 200-400 | 85 | 5-10 | 5 |
| THR20x18TU | 1200 | RU | RU | 2520-5400 | 13-57 | 200-400 | 85 | 5-10 | 5 |
Tobee® TH20x18 Mill Discharge Pump Structural Drawing:
Tobee® TH20x18 Mill Discharge Pump Structural Design:
Coal slurry pump
Diamond slurry pump
Aluminium slurry pump
Gold slurry pump
Platinum slurry pump
Phosphate slurry pump
Copper slurry pump
Zinc slurry pump
Iron Ore slurry pump
Paper slurry pump
Pulp slurry pump
Gypsum slurry pump
