SPECIFICATIONS:
Size: 16" x 14"
Capacity: 1368-3060m3/h
Head: 11-63m
Speed: 250-550rpm
NPSHr: 4-10m
Eff.: 79%
Power: Max.1200kw
Handling solids: 135mm
Seal arrangement: Packing seal, Expeller seal, Mechanical seal
Materials: High chrome alloy, Rubber, Polyurethane,Ceramic etc
Tobee® TH16x14 Minerals Slurry Pump is cantilevered, horizontal, heay duty slurry pumps. Designed for handling abrasive and high density slurries in the minerals process, metallurgical, mining, coal, power, building material and other industrial departments etc. The 16x14 slurry pump can be installed in multistage series. The metal lined and rubber lined is interchangeable as different medium.
Design Features:
• Cantilevered, horizontal, centrifugal, single stage, heay duty slurry pump
• Long bearing life: The bearing assembly is with large diameter shaft and short overhang.
• Anti-abrasion wet parts: The wet parts can be made of pressure molded rubber. They are completely interchangeable with metal wet parts.
• Easy adjustment of impeller: An impeller adjustment mechanism is provided below the bearing housing.
• Expeller seal , mechanical seal and packing seal are available.
• Various drive types: DC(direct connection), V-belt drive, gear box reducer, hydraulic couplings, VFD, SCR control etc
• Widely application: Designed for handling abrasive, high density slurries in the metallurgical, mining, coal, power, building material and other industrial departments.
Tobee® TH16x14 Minerals Slurry Pump Performance Parameters:
| Model |
Max.Power (kw) |
Materials | Clear water performance |
Impeller Vane No. |
|||||
| Liner | Impeller |
Capacity Q (m3/h) |
Head H (m) |
Speed n (rpm) |
Eff. η (%) |
NPSH (m) |
|||
| TH16x14ST | 560 | M | M | 1368-3060 | 11-63 | 250-550 | 79 | 4-10 | 5 |
| TH16x14TU | 1200 | ||||||||
| TH16x14ST | 560 | RU | RU | 1368-3060 | 11-63 | 250-550 | 79 | 4-10 | 5 |
| TH16x14TU | 1200 | ||||||||
Tobee® TH16x14 Minerals Slurry Pump Structural Drawing:
