Molecular Sieve Filling Machine for insulating glass production/Double glass Auto Desiccant Filling Machine (DFG02)
Desiccant filling machine for double glass/insulating glass/vacuum glass/double glazing glass
1. Main Function Introduction
1).PLC system to control the operation.
2).This machine is suitable to fill the spacer shaped by the automatic spacer bending machine and the Normal straight pin spacer.
3).The filling height can be adjusted according to the size of the aluminum spacer.
4).It can feed the needed desiccant automatically.
5).It owns the unique and advanced feeding device.
6).The key component are supplied by international well-known manufactures.
Kindly note:
Before you buy the machine, please make sure then tell me your local power supply,then we can make the right according to your true voltage.
2.Main technology introduction
model |
DFG02 |
Power supply |
AC220V,50HZ, 1KW |
Desiccant diameter |
0.5-0.8mm |
Filling aluminum spacer size |
min 150*150mm |
max 2000*2000mm | |
Filling speed |
5-8s(1000*1000mm9A) |
Aluminum spacer size |
6-24mm |
Air supply |
0.6MPa |
Power supply |
AC220V,50HZ, 1KW |
Figure Dimension |
800×800×3650mm |
Total Weight |
300Kg |
3.Desiccant photo
4.Insulating glass/double glass/hollow glass good advantages
1).sound insulation, noise reduction
2).keep warm
3).dust prevention
uce thermal radiation
5.Insulating glass/double glass/hollow glass good advantages
1).sound insulation, noise reduction
2).keep warm
3).dust prevention
4).reduce thermal radiation
6. Related insulating glass processing flow chart
If you want to buy this Desiccant Automatic Filling Machine ,you can add it in above processing line.
Besides you buy the basic vertical production line, you also need to add some accesary machines, such as Butyl extruder machine, two component coating machine, alu-spacer cutting saw, glass adge polishing machine etc.
About the full insulating glass production steps, here I can give you a brief introduction for your reference:
If you want to save some cost about the vertical production line, you can consider to by these basic machines is enough:
1).insulating glass/double glass/hollow glass production line, model: LB1800P
2). Butyl glue extruder machine, model : JT01
3).Two component glue coating machine, model: ST01
4).Rotary coating machine, model: SZT01 (this machine together work with the two component glue coating machine)
5).Glass edge polishing machine, model: SM95
7.Insulating glass/double glass product
8.Insulating glass structure
9.Kindly note
You may need to buy some small materials for the production,if you need, you can contact me,such as Desiccant, Rubber corner jointer, Alu-spacer bar...
1).Desiccant
2).Rubber corner jointer
3.Alu-spacer bar
10. Contact information
