Aluminium profile 3 axis cnc machining center
1. CNC Vertical 3 axis machining centre is used for processing aluminum profile, light alloys, pvc and steel.
2.Equipped with high power Water-cooled electric spindle and ISO30 standard tool handle.
3. Tool cutter change system automatically. The movable up-down tool magazine can equipped with 8 tools, using for drilling, milling and tapping, plus one Disc milling cutter(Max diameter 150mm) with 8 standard cutter tools.
4.Micro lubricating device. Screen system, motor driving belt crumb collection system. Cutter tool automatically measuring function, double-location processing, one-time clamping finish all production.
Product Model | Tango 1 | Tango 2 | Tango 3 |
Axis | 3 axis | 4 axis | 5 axis |
Band | DECALUMA | ||
X axis longitudinal stroke | 7630 mm | ||
Y axis horizontal stroke | 1246 mm | ||
Z axis vertical stroke | 575 mm | ||
Motor power | 7.5kw | 7.5kw | 12kw |
Spindle | HSD(Italy brand) Water-cooled Spindle | ||
Tool magazine number | 8 N° | ||
Max torque | 12000rpm 6 Nm | ||
Max rotary speed | 22.000 rpm | 24.000 rpm | 24.000 rpm |
Product weight | 5100KG | ||
Product Dimension | 9000*2110*2550mm | ||
Certification | CE | ||
Warranty | 1 Year | ||
Total power | 28.32 Kw | ||
After-sales Service Provided | Field installation, commissioning and training | ||
JINAN DEGA MACHINE CO.,LTD.(DECALUMA) was founded in 2006, offering products that include a wide range of machine for manufacturing aluminum window door & curtain wall, single and double-head sawing machines, machines and equipment for working and assembling aluminium and PVC window frames. We started as a small operation, but now we are the leading premium supplier in the segment of profile & curtain wall machining for a vast array of different requirements and materials. DECALUMA is a customer-oriented company,we are always just around the corner from you to help you choose a good machine, such as: cnc machining centre, aluminum cutting machine, aluminum hole punching machine, corner key cutting saw, aluminum profile drilling machine, corner crimping machine, end milling machine, aluminum profile bending machine, copy router and thermal break machine and so on.
1. What you can do if my machine have some problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines
2. what services can provide in your company ?
1) one year guarantee
2) free adjustment
3) free training to operation and maintenance workers.
4) free industrial information
5) free investment analysis for windows, doors and curtain wall project.
6) free layout design for windows,doors and curtain wall production lines.
7) provide follow-up service, regular maintenance and lifetime service for our machines sold.
8) provide technical support including pressure design and caculation for window and curtain wall companies.
9) provide quick supply of spare parts for window and curtain wall companies.
