VGM2500 Trade Assurance Vertical Automatic Insulating Glass Making Washing And Drying Machine
Machine Name: VGM2500 Trade Assurance Vertical Automatic Insulating Glass Making Washing And Drying Machine
Machine Model: VGM2500
Machine Function
This Vertical Automatic Insulating Glass Making Washing And Drying Machine can vertical wash and dry the glass automatically.
Germany technology blowing knife, which distance can be adjusted according to glass thickness.
Delivery back board adopts double surface polyurethane high strength MDF, which is suitable for the insulating glass work in long time.
Each transporting section adopts buffer stop function, which can avoid the bumping phenomenon and reduce the wear and tear of delivery wheel.
There is water mist separator in drying section, which can ensure glass drying fully.
This line has automatic LOW-E identification system and install special brush for LOW-E glass.
Cleaning section adopts high quality stainless steel material. It has 6 piece brush water cleaning device and 2 stages cleaning, which can ensure the glass clear enough. Special design spraying device, which angle can be adjusted according to demand. It is easy to be cleaned and maintained. Besides, it has water heating device. If the temperature is lower than 7°, we suggest that you can consider using it.
We uses anti-acid & alkali rubber delivery wheel.
Machine Technical Parameter
| No. | Technical Name | Technical Parameters |
| 1 | Power Supply | 380V 50Hz 18Kw |
| 2 | Max. Original Glass Size | 2500*3000mm |
| 3 | Min. Original Glass Size | 200*450mm |
| 4 | Max. Thickness of Insulating Glass | 50mm |
| 5 | Max. Delivery Speed | 45m/min |
| 6 | Water Electric Conductivity | Less than 200us |
| 7 | Air Source | 0.5-0.8Mpa 0.8m3/min |
| 8 | Dimension | 10000*3100*3500m |
Finished Goods
Vertical Automatic Insulating Glass Making Washing And Drying Machine
High Quality Wheel
Vertical Automatic Insulating Glass Making Washing And Drying Machine
Glass Washing Part
Vertical Automatic Insulating Glass Making Washing And Drying Machine
Glass Dryer

The package and shipping is our follow-up item of our factory maketing work and prelude item of our factory after service work.
+ Our factory pay more attention to our machine package and shipping.
+ Package type: Wooden Case and Wooden Pallet.We do not suggest using the plastic cover only on our machines.
+ Shipping type: Sea transportation and Express transportation. We do not suggest using the land transportation.
- Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.
- We have our own spare parts warehouse for window door machines and insulating glass machines.
- We can reply for every customers within 24 hours.
- By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.
- CCI always looking for long term cooperaion, not one time deal.
As a path breaker in windoor machines of China, CCI Group creates and develops the brand-new high quality window machines and Insulating Glass Machines with 25 years hard working. Our aim is the best windoor machines and insulating glass machines manufuctuer from China.
Attaching much importance to quality and taking management and technology development as the impetus, CCI Group tacks the culture of operation excellence, and has obtained ISO9001-2000 edition and CE Qualification successively.
So far CCI Group has more than thirty offices around China, and has built many a foreign office, such as in Canada, Kazakstan, Vietnam and etc.
Now CCI Group has become the all-around equipments manufacturer, producing more than one hundred products, which includes UPVC Window Door Making Machines, aluminium door and window making machine, Aluminum Curtain Wall Processing Machine and Insulating Glass Processing Machines.
We would like to expand our cordial cooperation with you for better future.
CCI Factory CE certificate on year 2002
+ Most of upvc window door making machines were passed CE Certificate;
+ Most of insulating glass making machines were passed CE Certificate;
+ Several aluminium door and window making machines were passed CE Certificate.
CCI Factory Exhibtion
+ As you known, our factory has several oversea offices all over the world. Normally, our marketing manager and distributor join the local market exhibition by ourselves.
+ If you have chance to be together with us on exhibition, welcome to contact us our marketing manager face to face if you have any demand about machine or after service for machines.
+ Our company has two large fabricating factories;
+ Our factory has our own office building and staff apartment;
+ Our factory has more than 50 fabricating workers which have more than 10 years window door and insulating glass fabricating experience;
+ Any more details, welcome to contact us our customer service department at any time on line.
CCI Factory Customer Details:
+ Our factory export our machines to more than 57 countries and areas.
+ Here we make a simple introduction about our client countries: USA, Canada, Brazil, Russia, Ukraine, Turkey, India, Pakistan, Vietnam, Philippines, Cambodia, Tunis, Nigeria and so on.
+ Hope you can be the next client in near future.
Q1: What kind of factory is CCI?
CCI is aluminium & upvc window door machines and insulating glass machines manufacturing factory since year 1991. We passed CE European standard in year 2002.
Q2: How is Vertical Automatic Insulating Glass Making Washing And Drying Machine guarantee?
- 14 months after BL time, 2 months more than other suppliers; Some of machines is 24 months;
- 24 hours technical support feedback;
- Own window factory supply window fabrication support;
- Own machining factory, which can control the spare parts quality at high quality;
- Own accessories warehouse and user can enjoy the agent price.
Q3: How is delivery time?
We can delivery the machines within 2 working days if we have the machines in stock.
The common machine fabricating time is 3-7 days and CNC machine fabricating time is about 7-12 days. We also produce customized machines for you, the delivery time will be given after confirmation.
Q4: How is payment?
30% of amount as deposit and the balance should be paid by T/T or LC at sight, welcome trade assurance.
Q5: How is our package?
Wooden Pallet/ Wooden Case. In order to ensure high quality machine precision, the perfect package is necessary.
Q6: Why is price higher than other supplier?
We have our own machining factory and the high quality technical is our aim, so all of the details we choice cost-effective spare parts.
- All the electric parts and pneumatic parts are high quality. Most of them are imported from European and American market;
- Most of fabricating worker has more than 10 years working time. Their fabricating work is professional, the machines have high precision;
Maybe our machine's price is higher than some of machine suppliers, however, our machine's quality is much more better than them. CCI machines have highest cost-effective.
CCI is the best choice you choose.
If you are glass fabricator, looking for Vertical Automatic Insulating Glass Making Washing And Drying Machine for business expansion,
If you have interest to set up glass production line as your new business,
Or you have any questions about insulating glass machine,
All the parts of machine can do some changes to meet your requirements. Any details information or help you want, please contact with me.
- WhatsApp: 0086-13589148572
- Skype: freeman2599
- WeChat: 13589148572
- Wechat:
CCI team is here, ready for support. press "send", let's start !
