Thermal break assembly knurling machine with insertion for aluminum
| Relative Products |
| Machine Details: |
| Equipment Advantages |
1, Special equipment manufactured for thermal break aluminum profile.
2, It is used to knurl on the notch of thermal break aluminum profile to improve horizontal shear force of profile.
3, It is the key machine to increase shear strength, knurling slot of extrusion profile through rotating knife at a high speed.
4, Stepless speed regulation is available by using frequency converter.
5, Electric controlled lifting of knurling knife and more stable automatically changing of different profile is available.
6, It can work with laminating frame and clamping device which means the machine poccesses the function of knurling, strip feeding and laminating film sticking.
7, The machine can inster nylon or PVC strip into profile at the same time of knurling.
| Technical Data |
Brand Name |
Trump |
Model |
GLKC-05G |
Input power |
1.1Kw |
Power supply |
220V/50Hz |
Air pressure |
0.5~0.8MPa |
Feeding speed |
10-105m/min (stepless adjusting) |
| Knurling cutter diameter | 90mm |
Thermal break strip width |
0-40mm |
Max. processing profile section (W*H) |
240*380mm |
Overall dimension (L*W*H) |
1000*900*1500mm |
Profile support dimension (L*W*H) |
5000*450*900mm |
Weight |
600kg |
| Main Accessory |
Electric Component |
Schneider |
Buttons |
Schneider |
Electric relay |
Schneider |
Motor |
Chaoyang |
AC Contactor and Circuit Breaker |
Schneider |
| Packaging&Shipping |
| After Sale Service |
24 hours technical support by phone, email or skype (mickychenlimin) . 1years warranty period
Free traning and friendly English verson manual and operation video CD disk.
| Payment Terms |
♦ L/C, 30% deposit by T/T,70% spare payment L/C.
♦ T/T, 30% deposit by T/T,70% spare payment before shipment.
♦ Western Union or Paypal.
Our main product:
Trump is a manufacturer also trading company of
window machine, insulating glass processing machine and curtain wall machine
Our advantage:
Advance tech,high quality product,competitive price,CE Certification and best service.
| Our Cooperative Partners |
1.If we have special requirements for your machines, can you make customized one for me?
Answer:We can make customized machine for different customers, for example, different voltage, color, authorized brand for some electrical components.
2. When can we arrange shippment?
Answer:We usually arrange shippment in 15 days after getting deopsit, but customized machines should be more than 25 days.
3.What you can do if my machines have problems?
Answer: a.We can send you free components to you if your machines are in guarantee time.
b.We can send our enineers to repair your machines
4.How many machines do i need to buy if i open a new factory?
Altogether there are five machines.
