Help CenterLinear Motion Shale Shaker Replace Mi Swaco for Drilling
Related Products
Shale Shaker-Linear&Elliptical Motion
Shale Shaker,to some extent, to be knowned as the first and vital phase during the procedure of separation in Oil&Gas Drilling,Civil Construction or other challenging industries involved.
Shale Shaker KES produced, the most advanced model KAZTS114-AHB, offering optional Linear and Elliptical Motion, with cost-effective solutions plus award-winning service,the KES shale shaker is the latest in a long line of products designed expressly to exceed the demanding needs of today’s Oilfield drilling operations.
Shale Shaker, so with its compact footprint,industry-leading processing capacity,solids bypass prevention, and low maintenance cost,the KES shale shaker is suitable for all drilling applications where drilling performance and rig modularity are required. It is designed to bring maximum value to all clients.
Shale Shaker, besides the KAZTS114-AHB series, we also offer you common Linear Motion shale shaker ,and our specialist will you suggestions to solve your problems.
SHALE SHAKER(Dr.Mark 86017603164653) |
||||||
Model |
KAZS112-QDZ |
KAZS113-AHB |
KAZS114-AHB |
KAZS114-ALD |
KAZTS114-AHB |
|
Vibration Mode |
Linear Motion |
|||||
Treatment Capacity(m³/h) |
70 |
120 |
150 |
150 |
150 |
|
Motor(kw) |
2x0.75 |
2x1.72 |
2x1.94 |
2x1.94 |
2x1.94+0.4 |
|
Screen Qty |
2 |
3 |
4 |
4 |
4 |
|
Screen Size(mm) |
750x900 |
585x1165 |
585x1165 |
585x1165 |
585x1165 |
|
Screen Area(m²) |
1.35 |
2.04 |
2.73 |
2.73 |
2.73 |
|
Output Force(G) |
≤7.1 |
≤7.5 |
≤8.0 |
≤8.0 |
≤8.0 |
|
Double Amplitude(mm) |
3.92-5.62 |
4.14-5.96 |
4.4-6.34 |
4.4-6.34 |
4.4-6.34 |
|
Deck Adjustment |
+2° |
-3-+3° |
-3-+3° |
-3-+3° |
-3-+3° |
|
Weir Height(mm) |
550 |
885 |
885 |
885 |
885 |
|
Explosion-proof |
ExdllBt4/IECEX/A-TEX |
|||||
Weight(kg) |
837 |
1365 |
1553 |
1520 |
1633 |
|
Dimensions(mm) |
1940x1360x970 |
2322x1650x1400 |
2912x1650x1425 |
2650x1650x1425 |
2912x1650x1425 |
|
