High speed 5000rpm rotary joint slip ring,bore 38.1mm,2 - 24 conductors circuits through hole hollow slip ring

High speed 5000rpm rotary joint slip ring,bore 38.1mm,2 - 24 conductors circuits through hole hollow slip ring

JARCH slip ring through boreis  suited for electric slip ring applications,  where signals and power need to be transferred, and a through hole is required to pass either a shaft or other feed through.

Model Explanation:

The TH038 uses JARCH's fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force and low contact wear. It provides an economical, readily available solution when a compact through-bore configuration is required. This unit provides a 6.0mm through-bore for routing hydraulic or pneumatic lines. The 2~5 amps /circuit are available in 1-24 ring.

 Click here to contact us for more details.

High speed 5000rpm rotary joint slip ring,bore 38.1mm,2 - 24 conductors circuits through hole hollow slip ring

· Unique signal handling performance with minimal electrical circuit noise
· Tight packaging to fit in the most demanding space constraints
· Fully compatible with both analog and TTL control level signals
· Precision ball bearings for long life
· Sealed units available,IP67 optional
· Rugged anodized aluminum construction
· Available with Ethernet
· Rapid delivery

 Click here to contact us for more details.

High speed 5000rpm rotary joint slip ring,bore 38.1mm,2 - 24 conductors circuits through hole hollow slip ring

 The length of slip ring will be advised when rings and  current details are options . Please contact JARCH technical department.

High speed 5000rpm rotary joint slip ring,bore 38.1mm,2 - 24 conductors circuits through hole hollow slip ring

• Exhibit/display equipment

• Packaging / wrapping machinery

• Semiconductor handling systems

• Industrial machinery

• rotary index tables

• Process control equipment

• Heavy equipment turrets or cable reels

• Emergency lighting, robotics Palletizing machines, Option

• Medical equipment | rotary sensors, emergency lighting, robotics

• Miniature cable reels

  Click here to contact us for more details.
Installation Instructions:


Shaft Mounted

Flange mounted:

Ethernet slip ring                       FORJ Fiber optic rotary joint        A4H Mercury slip ring

Q1: Are you a factory or a trading company?

A: We are a professional manufactory with High-level R & D team.

Q2: How many types of the slip rings do you have?

A: We can supply all kinds of the slip rings.Such as minitary slip ring,customized sliring,

miniature slip ring,fiber optical slip ring,RF rotary joint,HD combined-type,

disc slip ring,wind power slip ring,solar power slip ring,through-bore slip ring, etc.

Q3: Can you supply the slip rings with high frequency signals and(or) optical communication signals.

A: Yes, we can supply mixed signals slip rings as your request.

Q4: what's the working life of your slip rings.

A: 30~50 millions revolutions for standard ones, 50~80 millions revolutions for special ones,

We also can supply much higher revolutions as your special requirement.

Q5: Do you supply OEM and ODM ?

A: Yes, we supply OEM and ODM.

Q6: What technical data should be provided for our customized slip ring model.

A: If you want to costomize the special slip ring model, you need provide details as below:

a.operatring speed(RPM)

b.the type of installation

c.outline size

d.channels(the No. of single wire besides cable)

e.rated voltage & current for power rings and signal rings

f.the signal type and related

parameters(very important)

g.operating temperature h.IP(sealing requirements)

Q7: How long is your production lead time?

A: It needs 7 to 15 days for standard products, 10 to 20 days for simple customized products,

15 to 40 days for complex customized porducts.

Q8: What's your delivery port?

A: Our delivery port is Shenzhen

Q9: How do you delivery our goods?

A: Usually small orders can be deliveried by air, big orders can be deliveried by sea.

It can be negotiated before delivering.

Remark:

If you have any other question, pls contac us without any hesitation.

JARCH is a professional manufacturer of slip rings and rotary joints,founded in 1998,located in Bao’an,Shenzhen,with more than 80 employees and 1000m2 plant.

We have 8 types of patented products at present and have established extensive and long-term cooperation with many domestic research institutes(Beijing University,SAS,,Beihang University,etc), and own a skilled management team.To creat the brand and do famous brand,we carry out strict performance ISO9001 standard of CQC.

Our slip rings are widely used in civil and military fields ranging from robot,spacecrafts, industrial automation, electric power generation, measurement instruments, medial equipments to building construction. Our main products have fiber optic rotary joint / Electro optical slip ring/ through bore slip ring/ Pneumatic electric rotary union/ Hydraulic rotary union/through bore slip ring/ Pneumatic rotary joint,etc.

Our products are sold to more than thirty provinces in China and exported to more than 38 countries. Our main customers have Huawei,Foxconn,Sany Heavy Industry,BYD,etc.

OEM and ODM are highly welcome!
