Help CenterHand Push Cold Paint Spraying Road Marking Equipment for Sale at Factory Price
Related Products
-
Cold Plastic Paint Two Components Road Marking MachineUS$ 3,000 - 3,000MOQ: 1 Set -
Hand-push Airless Cold Paint Spraying Road Marking MachineUS$ 4,000 - 6,000MOQ: 1 Set
-
Vehicle Truck Mounted Cold Spray Road Marking MachineUS$ 7,000 - 10,000MOQ: 1 Set
-
30 Years Factory Direct Sale Hand Push Cold Spraying Paint Airless Road Marking MachineUS$ 4,000 - 6,000MOQ: 1 Set
-
New Design Hand Push Cold Paint Spraying Marking Machine For RoadUS$ 4,000 - 6,000MOQ: 1 Set
New Design Hand Push Cold Spraying Paint Road Marking Machine
| | |
| Hand Push Hot Melt Thermoplastic Paint Highway Road Line Marking Machine | Electric Self Propelled Thermoplastic Paint Road Marking Machine | Hand Push Knife Coating Two Pack Double Components Road Marking Machine |
| | |
| Hand Push Hot Melt Thermoplastic Paint Highway Road Line Marking Machine | Self Propelled Automatic Vibrate Rasing Line Road Marking Machine | Hand Moving Cold Spraying Paint Road Marking Machine |
Engine Power:4.1kw
Paint Bucket Capacity:25L
Rotational Speed: 2500r/min
Spraying Width:100-400mm(adjustable)
Highest Pressure: 20Mpa(Paint Pressure)
Spraying Thickness: 0.2-0.4mm
Rated Pressure: 12Mpa(Lacquer pressure)
Suitable Viscosity:80-100KU
Spraying Pressure:10Mpa(Lacquer pressure)
Flow Rate:5 L/min
Spraying Head Model:23H35
Weight: 200kg
Marking Speed: 4-5km/h
Overall Measurment:1200×920×1050mm
XDLP-S100-400 Manual cold spraying marking machine
Hand-moving cold spraying marking machine is a special high pressure airless spraying equipment for road marking, suitable for marking road centerline, lane, parking line, dotted line, solid line, curve line, directional arrwo, words writing, crosswalk line on provincial road, national road, urban road and airport, sea port, parking lot, rural road etc. Also suitable for regular coating and water-soluble coating spraying of interior and exterior wall.
It is suitable for provincial road, national road, urban road and airport, wharf, parking lot, rural highway and other places of the road center line, lane, parting line, parking line, dotted line, solid line, curve, guide arrow, written word, crosswalk line, also suitable for internal and external wall with ordinary paint and water-soluble paint spraying. Also suitable for interior and exterior wall.
This machine powered by imported Honda Gasoline engine, driven by
This machine uses imported HONDA (Honda) gasoline engine as the power. Meanwhile, the piston pump with heavy flow and high effience driven by hydraulic cylinder through reciprocating motion to breathe coating, the marking speed can be up to 4-5 km per hour.
This marking machine is of small size, light weight, easy operating, and the marking line is clear, full and adhesive, suitble for all marking and spraying in various occasions.
Instructions:
1,Accumulator
2,Back Lacquer Valve
3,Paint(Coating) Bucket
4,Relief Valve
5,Hydraulic Cylinder
6,Steering Structure
7,Belt Cover
8,Gasoline Engine
9,Gasoline Box
10,Handlebar
11,Pressure Gauge
12,One-way Valve
13,Filte
14,Wheel
15,Tail Wheel System
16,Pointer
17,Spraying Gun
18,Gasoline Pump
19,Chain Coupling
20,Overflow Valve
21,Wire Spanner
1, 30 Years: 30 years in design, development and marketing relevant products
2, 15 years: 15 years in exporting relevant products to 509m courtries and areas of the world
3, 24 Hours: All enquiries or questions will be responsed and replied within 24 hours
