GEPT well received fixed gas transmitter

Product Description

GEPT series of fixed gas transmitter is designed to require strict monitoring of hazardous gas content and the development of gas detection equipment . Can detect a variety of toxic gases and flammable gases , using a standard 4-20mA signal output, convenient access to a variety of distributed control system and the secondary table .

Product Features

Standard two-wire / three-wire 4-20mA current signal output, compatible with the existing control unit or the DCS ( Distributed Control System )
Explosion safety chamber designed to meet the electrical safety regulatory requirements IEC61508 -site installation easy and fast
Plug the international standard intelligent sensors

Low limit, high limit audible and visual alarm indication , programmable control
Standard three- button , single -site single point of maintenance
Full range temperature digital automatic tracking compensation to ensure the accuracy of measurement .

Technical parameters

Working voltage : 24VDC (12 ~ 36VDC)

Response time : T90 ≤ 10s

Recovery time : less than 20 seconds
Resolution : less than 1μA
Accuracy : ± 3% FS ( conventional ) ± 1% FS ( custom )

Display unit :% LEL,% VOL,%, ppm
Ambient temperature : -40 ~ 70 °C
Humidity : 10 ~ 95% R.H.
Explosion-proof grade : Exd Ⅱ CT6 ( flameproof )
Housing material : aluminum explosion-proof enclosure
Protection class: IP66
Probe life : 24 months
