ZB-1D Double Basket Disintegration Tester

Brief introduction

ZB-1D intelligent instrument is developed and the disintegration of the electromechanical integration test equipment according to the provisions of the "Pharmacopoeia" about Chinese tablets, capsules, pills and other disintegration test. The main technical indicators are in line with the provisions of USP and BP on the detection of disintegration time limit.

Features

* two groups of left and right basket, can be independently performed the disintegration test.

* instrument automatic preset temperature is 37 degrees, and can be reset at any time preset temperature.

* preset time, the basket will stop automatically at the highest position, is loaded from the basket and the beaker.

* overheat alarm automatic protection function.

Technical parameters

Timing range: 10 hours in any setting, the display resolution is divided into

Temperature preset range: 30-40.0 C arbitrary set, the display resolution of 0.1

Temperature control accuracy: + 0.3

Basket lifting frequency: 30~32 times / min

Basket lifting amplitude: 55mm + 1mm

The screen to the bottom of the cup minimum spacing: 25mm + 2mm

Mesh size: 2mm (1mm, 0.425mm, factory standard), 0.71mm (the new provisions of the 2015 Pharmacopoeia)
