YM-100C(III) ATP Germ Meter Hygiene Level Analysis Instrument Chemiluminiscence Analyzer

Brief introduction

The Biolum-III portable ATP hygiene monitoring system is intended for on-site quick cleanliness (microbial content) test in various industries such as food processing, catering, medical sanitation, daily chemicals, paper makg, water treatment, environmental protection, water administration,entry-exit ins

Features

1.Small in size: handheld design, total weight is less than 300g,one-hand operation;
2. Low power consumption: lithium battery, duration time is up to 10 hours, standby time is up to 600 hours;
3. Auto operating mode: 3.5’ color screen, simple keys, and friendly HMI;
4. Quantified result: the test result is accurate to 1×10 -18 mol ATP;
5. Quick test: 10 seconds per sample. The Biolum-III detector can be connected to a thermal printer via Bluetooth. The test result can be printed in real time;
6. Test protection: the Biolum-III detector possesses built-in inclinometer which will stop the test in case the incline angle is out of range to ensure test accuracy;
7.  Control network: the Biolum-III detector can smartly check whether the bacterial colony amount is out of limit. It can be connected to electronic terminals such as PC;
8. Maximum storage capacity: the Biolum-III detector is capable of storing 256 Users, 256 Plans, 2000 Programs and 10000 Records;
9. Data template: the Biolum-III detector is integrated with data templates to facilitate user for viewing or calling;
10. Intelligent software: test data can be uploaded to the dedicated Biolum-III PC softwarafter test. Combine with this software, users could track, save the test results and analyze the trend of the tested locations.
11. Open reagent: suitable for ATP test reagents from multipl manufacturers. It is strongly recommended to use the supplied consumables to ensure the test result accuracy.

Technical parameters

Dimension: 189mm×70mm×35mm;
Weight: 280g;
Display screen: 3.5’ color screen, graphic HMI;
Start-up time: 15s and 60s available;
Test time: 10s;
Storage capacity: 256 Users, 256 Plans, 2000 Programs and 10000 Results;

Battery type: 3.7V rechargeable lithium battery, whose recharging voltage is limited to 4.2 V ±0.05V;
Battery capacity: 2500mAh (duration time is up to 10 hours,standby time is up to 600 hours);
Communication mode: the Biolum-III detector can be
connected to your PC via USB cable; and also can be connected
to mobile, tablet PC or printer via Bluetooth;
Real-time print: the Biolum-III detector can be connected to a
printer via Bluetooth, and the test result can be printed in real time;
Incline angle detection: this feature of Biolum-III detector ensures the test accuracy. The test will stop processing if the device incline angle is over 30°, and the screen will display icon as an alert;
Auto calibration: the Biolum-III detector possesses light source auto-calibration system and temperature detection system that can automatically be adapted to changes of environment;
