Real Time PCR Detection System LineGene 9600

Real Time PCR Detection System LineGene 9600 photo-1
US$ 6,950 - 18,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
BR
Place of Origin:
Shaanxi, China
Model Number:
LineGene 9600
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Brand Name BR
Place of Origin Shaanxi, China
Model Number LineGene 9600
Type Genes & Life Science Equipments

 Real time PCR Detection System LineGene 9600

Introduction

Based on our LineGene family consistent excellent quality, LineGene 9600 to offer you a larger sample size, detection channel more and more wide temperature range.

Different from other LineGene family models, model module radiating the patent technology and the bottom of the one and only detect patent gives temperature rate, LineGene 9600 faster temperature accuracy, uniformity and stability of temperature. LineGene 9600 has a large sample size of up to 96 samples and the ultrafast two-color scanning speed. And a new design of up to eight channels of the LineGene 9600 covering the wavelength range of fluorescence detection of all. LineGene 9600 is fluorescence quantitative PCR detection system of the new products. Based on our LineGene family consistent excellent quality, LineGene 9600 to offer you a larger sample size, detection channel more and more wide temperature range.

Different from other LineGene family models, model module radiating the patent technology and the bottom of the one and only detect patent gives temperature rate, LineGene 9600 faster temperature accuracy, uniformity and stability of temperature. LineGene 9600 has a large sample size of up to 96 samples and the ultrafast two-color scanning speed. And a new design of up to eight channels of the LineGene 9600 covering the wavelength range of fluorescence detection of all.

Technical Parameters



 Model9620964096609680
Sample Capacity96-Well PCR plate12*8-strip
96*0.2ml(Bottom Transparent)
Dynameics Range1~1010Copies
Excitation Wavelength300-800nm
Emission Wavelength500-800nm
Detected   FluorescenceF1:FAMSYBR Green I
F2:VICHEXTETJOE
F1:FAMSYBR Green I
F2:VICHEXTETJOE
F3:Cy3NEDTAMRA
F4:ROXTEXAS-RED
F1:FAMSYBR Green I;
F2:VICHEXTETJOE
    Cy3NEDTAMRA;
F3:ROXTEXAS-RED:
G4:Cy5;
F1:FAMSYBR Green I;
F2:VICHEXTETJOE
F3:Cy3NEDTAMRA
F4:ROXTEXAAS-RED
F5:Cy5
F6:Cy5.5
F1:FAMSYBR Green I
F2:VICHEXTETJOE
F3:CY3NEDTAMRA
F4:ROX  TEXAS-RED
F5:Cy5
F6:Cy5.5
F7F8 for Customized
Block Temp.Range
4 ~105 ℃ ( Minimun Increment  :  0.1 ℃ )
SOAK Low Temp.Consercation Function
Heating/Colling Rate4.0 ℃/s
Temp.Control Accuracy≤±0.1 ℃
Temp.Flustuation≤±0.1 ℃
Temp.Control Mode≤±0.3 ℃
Sample Volume RangeBLOCK/Tube Simulation Mode (Automatic Control based On Sample Volume )
Gradient Temp.Range5 ~100μl
Hot-lid Temp.Range1 ~36 ℃
Fluorescence Detection30 ~110 ℃ (Adjustable default 105 ℃ Automatic Hot-lid )
Repeatability5%
Scan ModeEntire Plate or Designated Line
ProgramMax 20 Segments for Each Program Max 99 Cycles
Operation ModeContinuous
Scan Period5.5s   ( F1/F2 96 Plate Scan)
Feature FunctionAbsolute Quantification , Relative Quantification ,SNP Analysis:
Data Automatic Analysis:Melting Curve;Gradient,Automatic Gain,
Customized;Multiple File Gene expression Analysis
Operation SystemMicrosoft  :  Windows2000/XP/vista/windows 7/windows 8
(Compatible with 64-bit operating system) Software  :  Excel2003/2007
PC ConfigurationMemory:512M     Hard Disk:10GB    CPU:Pentium® 4    Virtual Memory:≥1000MB
Power Supply100-240V ~ 50/60Hz   600W
Dimension ( L*W*H )430mm*395mm*352mm
Net Weight28kg
SocketUSB Adapter RS232C Adpater ( Optional )Blue Tooth Adapter ( Optional )
CertificatersFerrotec Pelitier / Met / CE / RoHS / CE-IVD

 Real time PCR Detection System LineGene 9600





Dear customer,

 We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history .

 Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science.

   Through a long-time development,we own a national resources system of various professional talents,abundant supply for various components & parts and special materials,full producing &processing equipments,strong Technological standardization and a complete quality assurance system.

    If you need OEM or ODM in manufacturing,scientific research,market development and or you want to build your own brand in your country,it’s our honor to cooperate with you.In this way,we have developed many products for our customers from the USA,Europe and South Africa and got good feedback on Alibaba.



 We firmly believe that science and technology is no boundaries.

Our mission is to make every effort to contribute to all humanity.
