ND-6100 Laser Airborne Air Particle Counter for Clean Room Pharmaceutical Factory

Brief introduction

ND-6100 laser dust particle counter is used to measure the size and number of dust particles in the unit volume air of clean environment, which can directly detect the clean environment of the grade of clean degree from three hundred thousand to 100. Instrument adopts semiconductor laser light source, large screen display, small size, light weight, high detection precision, operation simple, microprocessor control, storage, print the measuring results, the test environment is clean is very convenient. In addition, the data can be downloaded and stored by the special software of the computer. Products are widely used in electronics, optics, chemistry, food, cosmetics, medical and health, biological products, aerospace and other departments.

Features

1 Sampling flowrate: 100L /min, the United States imported fan, low noise.

2 stainless steel shell, more in line with the clean clean indoor surface disinfection

3 volume and weight to small light

4 large LCD screen display, touch screen operation, six channel diameter also showed the particle concentration

5 AC-DC, imported batteries, can be disassembled conveniently

6 95%UCL calculation, automatically determine the cleanliness level

7 printable, can be stored, can be imported into the computer

8 one of the most simple operation interface, most users who have used similar products can quickly grasp the operation skills without the instruction manual.

9 optional temperature and humidity sensors, wind speed sensor, pressure sensor

Technical parameter

Exterior dimension 250x261x216 (L * D * H)

Display color 7 inch LCD screen

Weight  7.7kg

Maximum power consumption 80W

The power of DC 24V built-in lithium battery

Particle sizes of 0.5, 1, 3, 5, 10, 25, (UM)

UCL 95%UCL reliability calculation, can directly display the particle concentration (A / M)

Test report optional ISO14644-1, the new version of GMP, the European Union GMP, 16292-2010, etc.

Sampling flow 100L/min

Choose between the detection period 0-9999sec

Self purification time less than 10min

Printer built-in type thermal printer

Alarm (clean level) level 100100010000 (Class)

The maximum permissible concentration of 35000 /L sampling

Continuous working hours 2-3 hours

Light source and service life of semiconductor lasers (lifetime of more than 30000 hours)

10000 data storage group use USB derived

Using ambient conditions of temperature: 10℃-35℃, humidity: 20%-75%, atmospheric pressure: 86kPa-106kPa

Measurement of auxiliary vehicles (stainless steel)
