ARX3100 Flue Gas Velocity Ultrasonic Flowrate Meter for Stack Chimney

Brief introduction

AX3100 insertion type ultrasonic flow meter using imported parts assembly and become, integration design, no moving parts, convenient installation, in the worst case, also can show remarkable durability, excellent can be repetitive, long period of stability.

AX3100 insertion type ultrasonic flowmeter measurement principle for ultrasonic phenomenon. The vortex generated in the fluid can be detected by the insertion of an ultrasonic wave, even at a low speed. The ultrasonic emission of the ultrasonic transmitter will be affected by the vortex, and then be received by the ultrasonic receiver, the linear relationship can be calculated through the signal processing.

Features

High precision, less than 1% of the measured value, can directly measure the flow rate (m/s), manual input temperature pressure for static temperature pressure compensation, can be output standard square and mass flow.

High reliability and long life. Robust mechanical design, enhanced type of sensor, permanent anti fatigue strength.

To adapt to high corrosion, high dust measurement media. The probe uses the HA's alloy and wear-resistant ceramic, IP68 protection level, no dead angle, easy to clean flush.

To meet the low flow rate, the lower limit of the flue gas flow rate is 0.3m/s.

Low maintenance, no need to blow, no blockage.

Small size, compact structure, small installation space required.

Large flue. Because it is a plug-in installation, can be used to measure the flow rate of 8 meters large pipes.

The detection range is wide, the range is high, easy to check. Relative to its type flow meter, ARX3100 measurement range is very wide, range than at least up to 1:200, can be measured to the minimum value of 0.3m/s, the maximum range can be up to 80m/s.

Technical parameter

The working principle is to measure the flow rate and the flow rate through the ultrasonic signal.

Condensing gas, dust containing gas and corrosive gas

Insert length 1500mm or custom length, can be adapted (0.3 ~ 8) m flue

Measurement range (0.3 ~ 40) m/s

The precision measurement value of 1%+0.3m/s "

Repeat measurements of 0.2%+0.025% FS

Output (4 ~ 20) mA (impedance: 400 ohms)

Power source 24VDC

Environment temperature (-20 ~ 50) relative humidity is less than or equal to 90% DEG C;

The temperature of the medium pressure temperature (-20 ~ 150) C; pressure is less than 0.3MPa
