ARX 5100 flue gas zirconia oxygen analyzer for stack chimney
Brief introduction
ARX 5100 oxygen analyzer can be used for measurement of combustion gas oxygen concentration, including combustion control of various industrial furnaces (power boilers, steel, petrochemical, heating, etc.), the detection of oxygen in inert gas; medical waste incineration furnace pollutants control; CEMS supporting control pollution emissions; refining the application of VOD furnace.
Features
Has the characteristics of intelligence, good stability, high reliability, long cycle calibration;
The 128 x 64 LCD screen display menu and set the data of oxygen concentration, and the state of the instrument, the surface of a toughened glass window superimposed to protect the LCD screen and keyboard;
The menu lock function to prevent misoperation caused by impact on the analyzer;
Temperature alarm and temperature protection function, when the header the internal temperature exceeds 60 DEG C, a temperature alarm, more than 70 DEG C will reduce the heating voltage of the sensor, temperature protection to the analyzer;
History storage data retrieval function, can view the specified date and time of the historical data storage;
Using the latest touch button technology, to extend the service life of the button;
A SPST alarm function (optional);
RS232/RS485 (optional) two-way communication function, can communicate directly with the computer or other digital communication equipment;
A group of isolated analog signal output, analog output mode can be set freely through the menu;
Insertion depth of the probe can be based on user customized conditions;
The probe can be accurately measured at up to 500 degrees Celsius in the environment.
Technical parameter
Measurement range O2 0~25.00% output signal (20 ~ 4) mA, RS232/RS485 (optional)
Probe length 600mm, 800mm, 1000mm, 1200mm, 1500mm, 1800mm special requirements can be customized response time T90 < 30S
Header size L * W * H=158 (mm) * 158 (mm) * 99.5 (mm) probe tube diameter of 40 (mm)
The power consumption of the power supply voltage is less than 35VA 24VDC
Accuracy of 0 ~ 9.9 NA ppm:
10 ~ 99.9 ppm: + 10ppm
100 ~ 999.9ppm: + 3%FS
1000 ~ 9999 ppm: + 3%FS
1 ~ 25%: measurement of the value of 3% complex 0 ~ 9.9 NA ppm:
10 ~ 99.9 ppm: + 5ppm
100 ~ 999.9ppm: + 1.5%FS
1000 ~ 9999 ppm: + 1.5%FS
1 ~ 25%: the measured value of + 1.5%
Stability of 0 ~ 9.9 NA ppm:
10 ~ 99.9 ppm: + 5ppm/7d
100 ~ 999.9ppm: + 1.5%FS/7d
1000 ~ 9999 ppm: + 1.5%FS/7d
1 - 25%: measurement of environmental temperature meter + 1.5%/7d use environment temperature: -10 ~50℃
Probe using ambient temperature: 0 ~ 500℃
