Help CenterHB6020(A) Automatic Smoke Flue Gas Monitor System
Related Products
-
ETW-6 Air Microorganism Sampler Icrobial Sampling Device 28.3lpmUS$ 3,840 - 4,800MOQ: 1 Set -
X3G 700 Handheld Environment AnalyzerUS$ 13,000 - 15,625MOQ: 1 Set
-
GXH-1050E NDIR Intelligent Online Process Gas AnalyzerUS$ 6,800 - 7,300MOQ: 1 Unit
-
EA090 Organic Matter Concentration DetectorUS$ 4,300 - 4,800MOQ: 1 Unit
-
EA093 Portable Air PM2.5 PM10 Concentration Meter AnalyzerUS$ 12,000 - 17,200MOQ: 1 Unit
Features
1. The integration of the whole machine, can measure the flue gas, dust, moisture content, flow velocity, dynamic pressure, static pressure, temperature, smoke lampblack (such as O2, SO2, NO, NO2, CO, CO2, H2S optional) flue gas emissions, excess air coefficient, etc. All the parameters.
2. According to different speed sampling and sampling method constant current sampling. When smoke sampling based on the pitot tube parallel speed sampling principle, can automatically track the flue gas flow speed sampling or constant current sampling (low velocity); The flue gas sampling, with constant flow sampling technique
3. This instrument integrates the temperature/pressure/flow/oxygen sensors, to measure including dynamic pressure, static pressure, gas flow rate, moisture content,
Oxygen levels,
4. The flue gas flow measurement and control adopts imported pressure sensors and electrochemical sensor measurement results more accurate. Electrochemical sensor and signal module integration design, replace the sensor without calibration, and have the function of temperature and the linear compensation and cross interference correction, ensure accuracy test. Smoke sampling flow sensor adopts the inner cone flowmeter, wide range, good linear, high accuracy of flow measurement
5. The sensing signal multistage photoelectric isolation technology, strong anti-jamming capability, to make measurement more stable and reliable
6. Adopts double CPU structure, the working state of the monitor each other, found that the error correction promptly; Adopt digital communication technology between CPU, input and output channels all adopt photoelectric isolation, make the instrument under the condition of strong interference can work normally
7. Can save 200 complete set of sample data, available for users real-time query
8. The sampling data is various, the user can according to your requirements to customize the print data, convenient and quick
9. The unique drying, filtration, prevent breath triad of drying cylinder design, can effective dry moisture, dust filter, and put breath in reduce the influence on traffic, achieve long-term operation no clean.
Technical parameter
Dynamic pressure:0-1500 pa
Thestatic pressure: - 30 - + 30 kpa
Gauge pressure before: - 30-0 kPa
Sampling flow:10 to 60 l/min
The flue gas temperature: 0-500 ℃
Dry bulb temperature: 0-100 ℃
Before the meter temperature: 0-100 ℃
Moisture content of 0-40%
Constant speed tracking accuracy + / - 3% or less
The machine power consumption: 0.2 KW or less
Flow stability of plus or minus 2% or less
Tracking response time: no more than 4 seconds
Dear customer,
We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history .
Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science.
Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system.
If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba
|
We firmly believe that science and technology is no boundaries Our mission is to make every effort to contribute to all humanity. |
