CU-600 Total Organic Carbon Analyzer

Features:

1. High precision, low detection limit

2. Touch screen design, human interface, simple operation is convenient

3. The conductivity temperature compensation technology, improve the accuracy of detection

4. No need for carrier gas and reagents, simple maintenance and low cost

5. Separate system applicability test interface, operating more human

6. Testing curve in real time, more intuitive

7. Large data storage, query convenient, and can query by date

8. The built-in stylus printer, reduce the occupied space

9. Uv lamp life countdown, convenient for uv lamp replacement and maintenance

10. External 4-20 ma

11. Beyond the limit alarm output function

12. Optional on-line sampling device, the realization of the water system of on-line monitoring

13. Optional automatic calibration package, a key to complete the automatic calibration and system applicability test

14. Optional automatic sampling instrument, to realize unattended, save manpower and time

Technical parameters

TOC detection range: 0.1 ~ g/L ~ 1500.0ug/L

TOC detection accuracy: 0.1 g/L (1.0uS/cm)

Can be detected items: TOC, electrical conductivity, temperature

Electrical conductivity detection range: 0.055-6.000uS/cm

TOC error: less than 5%

Repeatability error: less than 3%

Time: the analysis of the shortest 20s interval (set).

Response time: 15min

Sample temperature: 0 ~ 100
