Help CenterLHD004 Electric Ceramic Hot Plate Magnetic LED Digital Hotplate Stirrer for Laboratory Experiment
Related Products
-
LHD005 Experimental Use Laboratory Temperature Controllable Electric Heating Plate HotplateUS$ 600 - 700MOQ: 1 Set -
LHD006 Cryogenic Constant Temperature TankUS$ 1,000 - 1,200MOQ: 1 Set
-
HCF -400S Handheld Ultrasonic Cell CrusherUS$ 2,380 - 2,580MOQ: 1 Set
-
LabSen 552 Plastic Puncture PH ElectrodeUS$ 1 - 150MOQ: 1 Set
-
HX -21 Y Rapid Organization Cell DisruptionUS$ 2,380 - 2,500MOQ: 1 Set
Introduction
HP550 -s digital type ceramic heating plate is on the market at present value of the high temperature heating plate, ceramic panel corrosion resistance, can be used for heating of most chemicals
Features:
• LED displays target and actual temperatures
• Temperature up to 550°C.
• Separate safety circuits with fixed safety temperature of 580°C
• PT1000 external temperature sensor is available. The control accuracy is ±0.5°C
• "HOT" sign warning to prevent burns, even if switched off.
Technical Parameter
Heating plate size [mm] |
184x184 |
Material of heating plate |
Glass ceramics |
Heating Area [mm] |
176x176 |
Heat output power [W] |
1000 |
Heating plate temperature range [° C] |
Room temperature—550 |
Safety temperature [° C] |
580 |
Temperature display |
LED |
Temperature display resolution [° C] |
1 |
External temperature sensor |
PT1000 |
External temperature sensor Temperature Accuracy [± ° C] |
0.5 |
Heat warning function |
50°C Alarm line |
Voltage [VAC] |
100-120/200-240 |
Frequency [Hz] |
50/60 |
Dimensions [W x D x H] mm |
215 x 360 x 112 |
Permissible ambient temperature [℃] |
4.5 |
Permissible ambient humidity |
5-40 |
Permissible ambient humidity |
80% |
DIN EN60529 protection |
IP21 |
Option accessories | |
PT1000-A |
External temperature probe, length 230mm |
PT1000-B |
Glass set external temperature probe, length 230mm |
PT1000-C |
External temperature probe, length 100mm |
MSPS01 |
PT1000 temperature probe support assembly |
