HCM100-ProHM100-Pro Thermo Mix

 HCM100-ProHM100-Pro Thermo Mix

Introduction

HCM100-Pro / HM100-Pro metal bath temperature oscillation has an excellent temperature control system. At room temperature, it is possible for the temperature range of 15 ~ 100 ℃ for accurate control

Features:

Excellent temperature control system, the temp range is 15°C below room temp.~ 100°C

Maximum temperature accuracy ( 20-45°C ) is ± 0.5 °C

Efficient mixing up to 1500 rpm ( depends on the heating

block )

Many different heating block

Have the program edit and store function

Technical parameters:

1 Function: Heating and Cooling & Mix (HCM100-Pro), heating & mixing (HM100-Pro)

2 Temperature control range:  low below room temperature 15 ℃, 100 ℃ (HCM100-Pro),  Low temperature higher than 15 ℃, 100 ℃ (HM100-Pro)

3 Temperature setting range: 0.1 ℃ / 100 ℃ (HCM100-Pro), 15 ℃ / 100 ℃ (HM100-Pro)

4 Temperature control accuracy: ± 0.5 ℃ (20 ~ 45 ℃)

5 Temperature uniformity: ± 0.5 ℃ (20 ~ 45 ℃)

6 Heating rate: 5.5 ℃ / min

7 Cooling rate: 2.5 ℃ / min (100 ℃ to room temperature), 0.5 ℃ / min (below room temperature) (HCM100-Pro)

8 Speed range: 300 to 1500 rev / min

9 Mix Diameter: 3mm

10 Display Specifications: LCD

11 Programming: 6 segment

12 Input voltage: 100 ~ 120V / 220 ~ 240V / 50Hz / 60Hz

13 Power: 200W

14 Dimensions: length × width × height = 200 × 235 × 120mm

15 Working temperature: 5 ~ 40 ℃

16 Humidity: 80%
