DY521 Automatic Fusion Machine Sample Melting Furnace

DY521 automatic fusion machine sample melting Furnace

Brief introduction

The first fully automatic fusion machine in China even the filling of the fusion sample;

Revolutionary result reaching the new peak of technic of manufacturing fusion machine;

No fluid coolant required,no harm of electromagnetic radiation comparing with High Frequency induction;

Same throughput,half energy consumption comparing with High Frequency induction.

Features

1.Fully automatic – Even the filling of the fusion sample.
2.Superior accuracy – Completely independent heaters for crucible and mold for optimal temperature control and measure.
3.Homogenization – Crucible is rotated while inclined, efficient agitation and superior homogenization of the melt, in less time.
4.Smoothness – Fusing and molding are processed separately.
5.Superior reproducibility–Fully automatic, superior accuracy, homogenization and smoothness ensure the superior reproducibility of the sample; all samples are uniformly the same except for the differences in composition.
6.Productivity – Overlapped processing of two samples: up to 50% time savings vs. other machines.
7.Economical –Minimal heat dissipation: casing remains cool;uses only a regular electrical outlet (consumes less than a hair dryer). Elegant and compact design.Takes up less space in the laboratory.
8.User-friendly–Plug-and-play: installs in seconds. Virtually maintenance-free; easy component access.Real-time temperature display,Operates free of supervision.Easy loading of crucibles,molds and beakers.10 independent and user-customizable programs available.
9.Reliable – Made with an electrical Joule-effect .

10.Versatility –XRF, AA and ICP fusion machine: both disk and solution unitsincluded. Can also readily do peroxide or pyrosulfate fusions.

Technical parameter

Maximum usable temperature: 1250℃, continuously adjustable;
Temperature measurement unit: 2 Pt-Rh thermocouples;
Throughput: 5~7samples/hour;
Wattage: 1200W;
Power supply: AC220~240V, 50~60Hz;
Dimension(Height × Width ×Depth): 430mm× 410mm× 430mm;
Weight: 27kg
