Home > Products > Analytical instruments > ELSD-UM5000 Evaporative Light- Scattering Detector
ELSD-UM5000 Evaporative Light- Scattering Detector
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | TONGWEI | Place of Origin | Shaanxi, China | |
| Model Number | ELSD-UM5000 |
Product Description
Introduction
Evaporative light-scattering detector has been widely applied in the carbohydrate, lipid, fatty acids, amino acids, drugs and polymer detection, especially the no violet absorption of active ingredients of traditional Chinese medicine and Chinese patent medicine.
UM5000 evaporative light-scattering detector, it is our company's new economical evaporative light-scattering detector; Is continued UM3000 and UM5000 after another classic. The performance of the instrument has been further optimization, at the same time, also has the economical, high cost performance, etc.
Technical parameters
Operating condition | 15~35℃,Relative humidity < 90% |
Evaporation temperature range | Room temperature ~ 130 |
Temperature regulation increment | 1℃ |
Temperature control precision | ±1℃ |
Gas requirements | Nitrogen or air |
Solvent flow rate | 10 µl~3 mL/min |
Gas input pressure | 2~5 bar |
Gas pressure measurement accuracy | 0.01bar |
Gas consumption | 1 ~ 4 L/min |
Power supply | 220 VAC, 50Hz |
light source | 650nm laser diode |
Detecting element | Photoelectric multiplier tube |
Detection limit | Ng <1 (glucose, direct injection) |
Typical quantitative range | 20 ~ 0.2 g (glucose, HPLC) |
Noise level | <0.1 mV (1ml/min ) |
Signal output | 0~10 m VDC,or 0~1 VDC |
Computer interface | RS232 |
Dear customer,
We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history .
Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science.
Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system.
If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba
We firmly believe that science and technology is no boundaries
Our mission is to make every effort to contribute to all humanity.
