Features:
1.Quality is much better than traditional solid laser marking machine, the output is TEMOO.
2.Lightning conversion efficiency to a maximum of 30%, leading to less than 500W electric consumption in total, accounting for 1/10 of the electric consumption of YAG laser.
3.Laser is no need for any maintenance, don't need to adjust or clean lens.
4.Laser long service life: Jiaoxi series optical fiber laser marking machine use laser diode, average working time is 100000 hours.
Why Laser Marking?
1 Permanent & indelible marking process.
2 Non-contact type – doesn’t produce stress or change physical properties of materials.
3 Clean and Safe process –Chemical-proof, water-proof, oil, grease & fuel-proof.
4 Internationally Accepted as Quality Marking Standard.
5 No pre or post processing – Can be done on finished products.
6 Automated – can be integrated with existing production or packaging line. Controlled by Computer.
7 Flexible – mark texts, alphanumeric, logos, bar codes, graphics, images, 2D data matrix code etc.
8 Hardness – doesn’t affect quality of marking.
9 Least set up time – no tooling and jigs required.
10 Least or virtually no consumables.
11 Enhances the aesthetical & monetary value of products.
12 Counterfeit & Forgery prevention, product tracking & identification and so on.
Laser Marking Usage
1 Marking Alphanumeric, Serial Numbers, Part Numbers
2 Marking of Logos, Schematics, Complex Graphics, Images and Pictures
3 Bar-coding, 2D Data Matrix Codes, Lot Codes, Date Codes
4 UID Marking (Unique Identification)
5 Deep Engraving
6 Paint Removal from Plastic and Metal Surfaces
| Laser wavelength | 1064nm |
| Power adjustment range | 10-100% |
| Repetition frequency | 20-80KHz |
| Output beam quality | |
| Marking linear depth | 0.01-0.2mm |
| Min. Spot diameter | 0.01mm |
| Min. Character size | 0.1mm |
| Repetition accuracy | ±0.002mm |
| Max. Liner marking speed | 7000mm/s |
| Marking format | PLT, DXF, CDR, AI, DWG, etc. |
| Software | EZCAD |
| Standard marking area | 20W 100×100mm / 30W 100×100mm |
| Cutting metal thickness | 0.6mm @ loop>30 |
| Power consumed | |
| Electrical demand | 220V 10%/50Hz/4A |
| Cooling mode | Air-cooling |
| Control interface | USB |
| Laser module life | 100,000 hours |
| Machine Size & Weight | Portable: 210×740×560mm 45Kg |
| Usage environment | Clean,no shaking |
