Pre-fabricated Branched Cable
- Tianjin port Qingdao port or other main port
- T/T Credit Card
You May Like
-
35mm Pre Branch Pvc Insulated Electric Power Cable
-
YF-NH--YJV 2-5 Cores 150mm 0.6/1KV Xlpe Insulate Pvc Sheath Power Cable
-
Multi-core Pre-fabricated Branched Cable
-
6/10KV Aluminum Conductor1*95mm2 1*185mm2 XLPE Insulation PVC Sheath Power Cable
-
MV Power Cable 1*120mm2 Copper/ Aluminum Conductor XLPE Insulation Copper Wire Copper Tape Shield PVC Sheath Power Cable
-
IEC60502 Standard 1*95 Mm2 CU/AL/XLPE/CWS/CTS/PVC Unarmored Cable
Product Details
| Brand Name | RNEDA | Place of Origin | Hebei, China | |
| Model Number | Prefabricated branched cables | Type | Low Voltage | |
| Insulation Material | XLPE | |||
Product Description
TOP TEN CABLE MANUFACTURER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY
Pre-fabricated branched cable
Used in residential, high-rise office buildings, tunnels, hotels, hospitals, shopping malls and other power distribution system can also be applied to the main line with branch line requirements of the lighting system (roads, bridges, tunnels and airport runway).
Specifications
Prefabricated branch cables
Standard XLPE/PVC Copper Cables
BS7889/IEC502
600/1000V
Prefabricated branch cables
Prefabricated branch cable with rated voltage 0.6/1KVis a new Kind of low voltage distribution products. The prefab style can decrease the labor intensity greatly, shorten work time, and reduce cost greatly.
According to the IEC60502 and JIS376A. The insulation performance is much superior than IEC60502, and the joint is tested according to the standard of GB9732.
1. Rated power-frequency voltage U0/U: 450/750V, 300/500V and 300/300V.
2. Maximum permitted operating temperature of conductor is 60°C.
3. Permitted lowest working temperature is -35°C.
4. Cables can be used at places contaminated by mineral oil and fuel oil.
5. D more than 25mm
The minimum bending radius is over 6 times of cable diameter.
D not less than 25mm
The minimum bending radius is over 4 times of cable diameter.
(D-Diameter of the cable)
| Type | Product Name | ||
| YFD-VV | PVC Insulation PVC Sheath Prefabricated branched cables | ||
| YFD-ZR-VV | PVC Insulation PVC Sheath Flame retardant Prefabricated branched cables(ZRA,ZRB,ZRC) | ||
| YFD-NH-VV | PVC Insulation PVC Sheath Fire resistant Prefabricated branched cables(NHA,NHB) | ||
| YFD-YJV | XLPE Insulation PVC Sheath Prefabricated branched cables | ||
| YFD-ZR-YJV | XLPE Insulation PVC Sheath Flame retardant Prefabricated branched cables(ZRA,ZRB,ZRC) | ||
| YFD-NH-YJV | XLPE Insulation PVC Sheath Fire resistant Prefabricated branched cables(NHA,NHB) | ||
| YFD-ZRWDEE | Halogen-free Low Smoke Flame retardant Prefabricated branched cables | ||
Main core cross-section(mm2) | Branch core cross-section(mm2) | Main core cross-section(mm2) | Branch core cross-section(mm2) |
| 10 | 2.5~10 | 240 | 10~240 |
| 16 | 2.5~16 | 300 | 10~300 |
| 25 | 2.5~25 | 400 | 10~400 |
| 35 | 4~35 | 500 | 10~500 |
| 50 | 4~50 | 630 | 16~630 |
| 70 | 6~70 | 800 | 16~800 |
| 95 | 6~95 | 1000 | 25~1000 |
| 120 | 6~120 | 1200 | 25~1200 |
| 150 | 10~150 | 1600 | 50~1600 |
| 185 | 10~185 | ||
1.24 years production experience and 14 years export experience .
2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3.OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7.Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.
HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,
KEMA,CE and many other certifications.
We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At thte same time, we have obtained ISO9001,ISO14001,
OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificates.
1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
