Brand Name
beigao
Place of Origin
Beijing, China
Model Number
H71/W
Material
Stainless Steel
Structure
Check
Standard or Nonstandard
Standard
Pressure
Low Pressure
Power
Other
Port Size
DN50-DN600
Media
Water
Temperature of Media
Low Temperature
Dual Plate Wafer Swing Check Valve
Technical data
Size:DN50-DN600
Working pressure :pn16
Face to Face: DIN3202-K3
Flange drilling: ANSI 1125,EN1-92PN16,AS2129 TABLE D/E
Inspection and Test: API 598
Material of construction
Description | Material | Specification |
Body | Cast Iron | A 126B CF8 |
Disc | Stainless Steel | A 351 CF8M |
Hinge Arm | Stainless Steel | A 351 CF8M |
Seat | EPDM |
|
Hinge Pin | Stainless Steel | AISI 410 |
Spring | Stainless Steel | AISI 304 |
Application
The valve is used for preventing the back-going of medium in pipelines and equipments, and the pressure of medium will bring the result of opening and closing automatically.When the medium is back-going, valve disc will automaticaly closed to avoid accidents.
