Help CenterSingle Door Swing Check Valve
US$ 5.00 - 15.00
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
BEIGAO
Place of Origin:
Beijing, China
Model Number:
H7/W
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Check ValveUS$ 100 - 100MOQ: 200 Pieces -
DN50 Check Valve Ductile Iron BodyUS$ 6.54 - 749.4MOQ: 1 Set
-
Best Quality Promotional DN200 Dual Plate Wafer Type Silent Check ValveUS$ 20 - 20MOQ: 5 Pieces
-
Cast Iron /GG25/GGG40/GGG50 Lug Dual Plate Check ValveUS$ 20 - 20MOQ: 5 Sets
-
DN150 Wafer Dual Disc Butterfly Check ValveUS$ 20 - 20MOQ: 5 Sets
Brand Name
BEIGAO
Place of Origin
Beijing, China
Model Number
H7/W
Material
Stainless Steel
Structure
Check
Standard or Nonstandard
Standard
Pressure
Medium Pressure
Port Size
DN32~DN600
Media
Water
Temperature of Media
Normal Temperature
Single Check Valve
New promotion begins ! do not miss it ..............................................................
Technical data
Size:DN32-DN600
Working pressure :PN6/PN10/PN16
Flange drilling: EN1092-2 PN16
Inspection and Test: API 598
Material of construction
Description |
Material |
Specification |
Body |
Stainless Steel |
A351 CF8M |
Disc |
Stainless Steel |
A 351 CF8M |
Spring |
Stainless Steel |
AISI 316 |
Hook |
Stainless Steel |
AISI 316 |
Screw |
Stainless Steel |
A351 CF8 |
Seat Ring |
EPDM |
|
O Ring |
EPDM |
|
Application
The Valve is used for preventing the back-going of medium in pipelines and equipments, and the pressure of medium will bring the result of opening and closing automatically.When the medium is back-going, valve disc will automaticaly closed to avoid accidents.
