8 inch horizontal multistage electric water pump
- 500 Set / Sets per Month
- TIANJIN QINGDAO SHANGHAI NINGBO GUANGZHOU
- T/T Credit Card
Product Details
Brand Name: | MILESTONE | Place of Origin: | Hebei, China | Model Number: | MST-D |
Power: | Electric | ||||
Usage: | Water | Theory: | Centrifugal Pump | Standard or Nonstandard: | Standard |
Structure: | Multistage Pump | Pressure: | High Pressure |
Product Description
8 inch horizontal multistage electric water pump
D/DA 8 inch horizontal multistage electric water pump is an energy-saving product series performance parameters and technical data are higher. 8 inch horizontal multistage electric water pump is suitable for the circulation and pressurization of cold and warm clear water in high-pressure operation system, water supply under parallel operation of several pumps in civil construction, water supply for fire control, boiler, cooling water system and the delivery of various liquid.
Basic performance data
Max. Flow | 840m³/h |
Max.Head: | 1000m |
Max. Power: | 1800kw |
Speed: | 1450rpm/2900rpm |
Stage: | 2~12 |
Material: | Cast iron,Cast steel, Ductile iron |
Pump Structure:
1 | bearing cover | 2 | nut | 3 | bearing | 4 | water baffle |
5 | bearing base | 6 | shaft sleeve | 7 | gland packing | 8 | packing rings |
9 | suction part | 10 | middle bush | 11 | wearing rings | 12 | impellers |
13 | middle part | 14 | diffuser baffle | 15 | wing sleeve | 16 | tie bolts |
17 | discharge wing | 18 | balance bush | 19 | balance ring | 20 | balance ring |
21 | discharge part | 22 | stuffing box housing | 23 | shaft | 24 | shaft sleeve |
Pump Performance:
Pump Show:
Pump Application:
- long distance water transferring
- boiling water feeding and transferring
- water system boosting
- agricultural irrigation
- mining water supply
- fire fighting
- offshore projects
Technical Data:
Model | Capacity (m³/h) | Head (m) | Speed (rpm) | Motor Power (kw) | Impeller Dia (mm) |
6-25*5 | 6.3 | 125 | 2950 | 7.5 | 139 |
6-50*4 | 6.3 | 200 | 2950 | 18.5 | 198 |
12-25*4 | 12.5 | 100 | 2950 | 11 | 146 |
6-80*3 | 6 | 240 | 2950 | 18.5 | 235 |
12-80*4 | 12.5 | 320 | 2950 | 45 | 235 |
25-30*3 | 25 | 90 | 2950 | 15 | 160 |
46-30*5 | 46 | 150 | 2950 | 37 | 162 |
85-67*4 | 85 | 268 | 2950 | 110 | 235 |
120-50*5 | 120 | 250 | 2950 | 132 | 213 |
150-30*8 | 150 | 240 | 2950 | 160 | 172 |
150-100*6 | 150 | 600 | 2950 | 400 | 289 |
200-100*6 | 200 | 600 | 2950 | 560 | 290 |
280-65*6 | 280 | 390 | 1480 | 500 | 430 |
300-45*4 | 300 | 180 | 1480 | 200 | 360 |
150D30*6 | 155 | 180 | 1480 | 132 | 305 |
Who we are?
- 20 years experience of manufacture with 5 years oversea service.
- Advanced equipment with qualified engineers.
- Large foundry to control excellent quality.
Why always me, because we do pump right!!!
