Automatic Small Vertical Belt Automated Conveyor System
US$ 300 - 6,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
-
Small Vertical Belt Screw Automatic Conveyor System
-
Automated automatic hopper conveyor system
-
Hopper automated small conveyor belt system
-
Hopper Vertical Flexible Auger Screw Conveyor For Sludge
-
Hopper Belt Screw Conveyor System For Wastewater Treatment
-
Wastewater Treatment Tubular Powder Worm Screw Conveyor
Product Details
| Brand Name | QILEE | Place of Origin | Shanghai, China | |
| Certification | CE | |||
| After-sales Service Provided | Engineers available to service machinery overseas | Dimension(L*W*H) | 8.0m*4.0m | |
| Voltage | 220V/380V | Structure | Conveyor System | |
| Condition | New | Power(W) | 10000 | |
| Material Feature | Heat Resistant |
Product Description
PRODUCT CATEGORIES
Automatic Small Vertical Belt Automated Conveyor System
Product Description
Automated Conveyor System Features:
Adaptable for industry applications for large quantity of dry chemical (such as lime)
Pneumatic transported to life the chemical by chemical conveyor against free dust
Silo volume: 10~100m3
Dosing quantity: 50~2000L/h dry power
Equipped bin bottom activation device
Equipped powder metering and transporting device
Equipped bag filter
Material of construction: carbon steel epoxy Painted (stainless steel is as option)
Option: inlet water control unit, lime dissolving tank and mixed, etc.
Automated Conveyor System Features:
| Specification | Silo | Screw | Dissolving tank | Total powder | Floor area |
| Capacity (m3) | Diameter/Height | Treating Capacity(kg/h) | Diameter/Height | kw | Length*Width |
| QT- 10 | 1.9m/8.0m | 1- 50 | 1m/1.3m | 6 | 5.0m*3.0m |
| QT- 20 | 2.5m/8.0m | 5- 100 | 1.7m/1.5m | 8 | 6.0m*3.5m |
| QT- 30 | 2.9m/8.5m | 10- 200 | 2.0m/1.8m | 10 | 8.0m*4.0m |
| QT- 50 | 2.9m/11m | 50- 500 | 2.4m/2.2m | 14 | 10.0m*5.0m |
| QT- 70 | 4.0m/11m | 100- 1000 | 2.6m/2.5m | 20 | 12.0m*6.0m |
| QT- 100 | 5.0m/11m | 200- 1500 | 3.0m/3.0m | 25 | 13.0m*6.0m |
| QT- 150 | 6.0m/11m | 200- 2000 | 3.0m/3.0m | 28 | 13.0m*8.0m |
| QT- 200 | 6.0m/13m | 200- 3000 | 3.0m/3.0m | 30 | 13.0m*8.0m |
| QT- 300 | 8.0m/13.5m | 500- 5000 | 3.0m/3.0m | 30 | 15.0m*8.0m |
Automated Conveyor System Accessories:
Related Products
Packaging & Shipping
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
