china made 9kw/11.3kva air cooled gasoline generator
1. Specification of our china made 9kw/11.3kva air cooled gasoline generator
| Discrebtion | Generator Model | HY12000LE-3 |
| Reference | Open frame | |
| Diesle Generator | Rated Power(kW) | 9 |
| Max.Power(kVA) | 11.3 | |
| Frequency (Hz) | 50HZ | |
| Voltage (V) | 400/420 | |
| Current (A) | 16.3 | |
| Sockets | EU 1Phase 1x16A, 3phase 1x32A | |
| Display | LED4 | |
| Battery (Ah) | 12V/36Ah | |
| Fuel Tank Capacity (L) | 28 | |
| Running Time under 50% Load (hr.) | 6 | |
| Noise Level behind 7 Meters (dBA) | 79 | |
| DC Output (V/A) | 12/8.3 | |
| ATS connectroor | Option | |
| ATS control box | Option | |
| Remote Control as optional | Option | |
| Push Wheels kit as optional | Yes | |
| Engine | Engine | IC680E |
| Power Output (HP/3000rpm) | 20 | |
| Start Mothod | Electric | |
| Displacement (cc) | 678 | |
| Oil Capacity (L) | 1.5 | |
| Alternator | Alternator | 12.5KVA245L~130/G50(G60) |
| Rated Power (kW) | 12.5 | |
| Power Factor (Cosφ) | 0.8 | |
| Voltage Regulation | AVR / Brush type | |
| Transportation Data | N.G.kg | 172 |
| G.W.kg | 195 | |
| Product Dimension (mm) | 930*620*705 | |
| Package Dimension (mm) | 960*650*750 | |
| Max Quantity(set)/Container | 48/20GP;102/40GP;102/40HQ |
2. Why choose our 9KW 50hz three phase electric China made gasoline generator?
ITCPower Team |
ITCPower Factory |
ITCPower generator Certificate Show
|
ITCPower generator Show
|
How to come to ITCPower |
Service assurance of generator and other machines |
1. Before-sale Service:
We provide detailed product technical parameters for equipment choosing and system designing.
2. Service quality assurance:
Our sale staffs are all experience and professional,we can provide the most proper system design and optimized equipment for the customers.
3. After sale maintenance service:
We create files for end user and provide them follow-up service,regular return visit and permanent maintenance, We have distributors all over World that support after sale service.
4. Spare parts supply:
We provide all kinds of spare parts and technical support.
5. Main overhaul or maintenance service:
We provide perennial major overhaul and maintenance service.
Thanks for your attention to our 9KW 50hz three phase electric China made gasoline generator!
